Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Ventimax
-
Dimension(L*W*H):
-
1050*490*615
-
Weight:
-
27.4 KG
-
Working Temperature Range:
-
80 - 150 ℃
-
Function:
-
Fast Heating
-
Advantage:
-
Safty
-
Application:
-
Industry Heating Process
-
Heating Area:
-
400m2
-
Heating Volume:
-
1100(m³/h)
-
Fuel Consumption:
-
2.0-4.0L
Quick Details
-
Type:
-
Air Heater
-
Power Source:
-
Diesel
-
Voltage:
-
220V 50HZ
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Ventimax
-
Dimension(L*W*H):
-
1050*490*615
-
Weight:
-
27.4 KG
-
Working Temperature Range:
-
80 - 150 ℃
-
Function:
-
Fast Heating
-
Advantage:
-
Safty
-
Application:
-
Industry Heating Process
-
Heating Area:
-
400m2
-
Heating Volume:
-
1100(m³/h)
-
Fuel Consumption:
-
2.0-4.0L
Products Description
Performance Characteristics
1) Heating area:300-1800 square meters.
2) Effects of combustion chamber heightening design,with long service life.
3) Stainless steel dust collector ,simple,high efficiency.
4) Design of insulation three return ,the heat loss is reduced to the minimum.
5) The high thermal efficiency of 90%.
6) The unique 20 mm wall thickness of heat resistant cast steel pipe,ensure the combustion
ten years without deformation.
7) All the indicators have reached the national class I region environmental standards.
2) Effects of combustion chamber heightening design,with long service life.
3) Stainless steel dust collector ,simple,high efficiency.
4) Design of insulation three return ,the heat loss is reduced to the minimum.
5) The high thermal efficiency of 90%.
6) The unique 20 mm wall thickness of heat resistant cast steel pipe,ensure the combustion
ten years without deformation.
7) All the indicators have reached the national class I region environmental standards.
|
Technical Model
|
Voltage
|
Air Volume (m ³/h)
|
Fuel Consumption (L/H)
|
Power (KW)
|
Size(mm)
|
Weight (KG)NW
|
Heating Area(m²)
|
|
HYMR-20
|
220 V/50HZ
|
600
|
1.0-1.7
|
20
|
765*300*420
|
13.7
|
160
|
|
HYMR-30
|
220 V/50HZ
|
720
|
1.5-2.4
|
30
|
920*456*615
|
21.5
|
240
|
|
HYMR-50
|
220 V/50HZ
|
1100
|
2.0-4.0
|
50
|
1050*490*615
|
27.4
|
400
|
|
HYMR-70
|
220 V/50HZ
|
1300
|
2.5-5.4
|
70
|
1170*570*705
|
40.8
|
450
|
|
HYMR-100
|
220 V/50HZ
|
1500
|
4.0-8.0
|
100
|
1195*570*690
|
45.8
|
600
|
Details Images
Applications
It’s widely applied to greenhouse，poultry farm, livestock house, mining and factory buildings, also used in drying wood,
tea,medicine, foodstuff and other fields.
Related Products
Manufacturing Equipment
Ventimax
company produces push-pull type and swung hammer type exhaust fans, butterfly and fans, cow house hanging fans, non power roof fans, cooling pads, air cooler and other ventilating and humidifying equipment; it also manufactures automatic heating machines, manure scraper machines, automatic feeding and drinking systems, battery cages etc. The product series is more than 200.
Ventimax is always pursuing the best. With the development of enterprise, Hengyuan passed ISO 9001 international quality Certification, CE certification and realized the unity of international and domestic standards. Good quality, prompt delivery and timely after sales service gain the trust of customers. The domestic customers covers more then 30 provinces and oversea customers are from Europe,America, Canada, Australia, Asia, Middle East, Africa and other countries.
Ventimax is always pursuing the best. With the development of enterprise, Hengyuan passed ISO 9001 international quality Certification, CE certification and realized the unity of international and domestic standards. Good quality, prompt delivery and timely after sales service gain the trust of customers. The domestic customers covers more then 30 provinces and oversea customers are from Europe,America, Canada, Australia, Asia, Middle East, Africa and other countries.
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
