Quick Details
-
Max. Spindle Speed (r.p.m):
-
4000 r.p.m
-
Spindle Bore(mm):
-
36
-
Width of bed (mm):
-
25 mm
-
Spindle Motor Power(kW):
-
3.7
-
Travel (X Axis)(mm):
-
600 mm
-
Travel (Z Axis)(mm):
-
180 mm
-
Place of Origin:
-
Guangdong, China
-
Dimension(L*W*H):
-
1800*1500*1720mm
-
Brand Name:
-
YASHU
-
Model Number:
-
KX-36R600
-
Voltage:
-
380V
-
Weight (KG):
-
1500
-
Marketing Type:
-
New Product 2023
-
Product name:
-
CNC Lathe Mechine
-
After-sales Service Provided:
-
Video Technical Suppor
-
CNC or Not:
-
CNC
-
Machine Type:
-
Slant Bed CNC Lathe
-
Max. swing over bed:
-
350mm
-
After Warranty Service:
-
Video Technical Support
-
Processing material:
-
Aluminum Alloy Ect
-
X/Z axis travel:
-
600/200mm
-
Spindle speed:
-
3500rpm/min
-
Max. Swing Diameter:
-
350mm
Quick Details
-
Type:
-
Horizontal
-
Max. Length of Workpiece (mm):
-
180
-
Year:
-
2023
-
Max. Spindle Speed (r.p.m):
-
4000 r.p.m
-
Spindle Bore(mm):
-
36
-
Width of bed (mm):
-
25 mm
-
Spindle Motor Power(kW):
-
3.7
-
Travel (X Axis)(mm):
-
600 mm
-
Travel (Z Axis)(mm):
-
180 mm
-
Place of Origin:
-
Guangdong, China
-
Dimension(L*W*H):
-
1800*1500*1720mm
-
Brand Name:
-
YASHU
-
Model Number:
-
KX-36R600
-
Voltage:
-
380V
-
Weight (KG):
-
1500
-
Marketing Type:
-
New Product 2023
-
Product name:
-
CNC Lathe Mechine
-
After-sales Service Provided:
-
Video Technical Suppor
-
CNC or Not:
-
CNC
-
Machine Type:
-
Slant Bed CNC Lathe
-
Max. swing over bed:
-
350mm
-
After Warranty Service:
-
Video Technical Support
-
Processing material:
-
Aluminum Alloy Ect
-
X/Z axis travel:
-
600/200mm
-
Spindle speed:
-
3500rpm/min
-
Max. Swing Diameter:
-
350mm
Product Description
|
Technical Parameters
|
|
|
|
|
||||
|
Item
|
|
|
Standard
Value
|
Maximum Value
|
||||
|
Processing Capacity
|
Maximum bar material through-hole diameter
|
|
35mm
|
-
|
||||
|
|
Maximum granule diameter (disc type)
|
|
250mm
|
300mm
|
||||
|
|
Maximum processing work piece length
|
|
210mm
|
230mm
|
||||
|
|
Stainless steel single side cutting amount
|
|
2mm
|
3mm
|
||||
|
|
Work piece applicable machining accuracy
|
|
±0.01mm
|
-
|
||||
|
|
Machined surface smooth finish
|
|
1.6Ra
|
-
|
||||
|
|
Tool rest center height
|
|
40mm
|
-
|
||||
|
|
Machine tool turning diameter
|
|
250mm
|
-
|
||||
|
|
Square knife specifications
|
|
16mm
|
-
|
||||
|
Travel
|
X axis effective travel (diameter)
|
|
600mm
|
-
|
||||
|
|
Z axis effective travel
|
|
230mm
|
-
|
||||
|
Y Axis
|
Y axis type
|
|
Side face
4 live tooling
|
-
|
||||
|
|
Y axis travel
|
|
140mm
|
-
|
||||
|
|
Y axis power clamping type
|
|
ER16
|
-
|
||||
|
|
Y axis maximum speed
|
|
2500rpm
|
4000rpm
|
||||
|
|
Y axis fast moving speed
|
|
15m/min
|
-
|
||||
|
|
Maximum drilling and tapping diameter
|
|
Medium carbon steel 6mm / Aluminum copper 8mm
|
-
|
||||
|
Feed
|
X axis fast moving speed
|
|
25m/min
|
30m/min
|
||||
|
|
Z axis fast moving speed
|
|
25m/min
|
30m/min
|
||||
|
|
X axis servo power
|
|
1.3KW
|
-
|
||||
|
|
Z axis servo power
|
|
1.3KW
|
-
|
||||
|
Spindle
|
Maximum spindle speed
|
|
3500rpm
|
4000rpm
|
||||
|
|
Spindle motor power
|
|
3.7KW
|
-
|
||||
|
|
Spindle nose model
|
|
A2-4
|
|
||||
|
|
Hydraulic chuck available dimensions
|
|
6 inches
|
8 inches
|
||||
|
Size & Weight
|
External dimensions
|
|
Estimated 1750*1400*1800mm
|
-
|
||||
|
|
Overall weight / Net weight
|
|
Estimated 1800KGs
|
-
|
||||
|
Machine Tool Specifications
and Component Items
|
|
Specifications
|
Standard Configuration
|
Optional Configuration
|
||||
|
Component Specifications
|
Lead screw
|
25mm
|
Taiwan ball grinding precision grade
|
-
|
||||
|
|
Guide rail
|
25mm
|
Taiwan H-class linear guide rail
|
-
|
||||
|
|
Axle bearing
|
7015 / 7013
|
XEZ precision bearing or Harbin high speed angular contact bearing
|
|
||||
|
|
Spindle motor
|
3.7KW
|
3.7KW servo spindle
|
5.5KW servo spindle
|
||||
|
|
Feed servo
|
1.3KW
|
Yashu & DMC invent joint developed high speed servo
|
-
|
||||
|
|
Numerical control system
|
-
|
Yashu - KaiTong joint developed system
|
GSK / Taiwan SYNTEC / Others
|
||||
|
Machine Tool Specifications
|
Lathe bed form
|
30 degrees
|
Slanting bed lathe
|
-
|
||||
|
|
Base form
|
-
|
Heavy duty anti deformation patented base
|
-
|
||||
|
|
Clamping method
|
-
|
Hydraulic clamping
|
-
|
||||
|
Optional Devices for the Machine
|
Oil bar feeder / Full automatic feeder
|
|
|
|
||||
