uboot and openwrt sdk open support, can be widely used in fire, armed police, military and other fields of emergency communications. Army and other areas of emergency communications.
- Product Details
- {{item.text}}
Quick Details
-
Color:
-
White
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
XINGKAITECH
-
Model Number:
-
Drone Transmitter and Receiver XK-M372B
-
Color:
-
White
Product Description
|
Product Name
|
XK-M372B
|
|
Function
|
Drone Transmitter and Receiver
|
|
Package
|
Packed in a Professional Shipping Box
|
1. Product Description
uboot and openwrt sdk open support, can be widely used in fire, armed police, military and other fields of emergency communications. Army and other areas of emergency communications.
2. Product Features
- Maximum number rate up to 300Mbps
- The transmission distance of 10-20km without obstacles
- Self-assembled network scale not less than 50 units, relay capacity more
than 10 hops
- Platform provides open support of immortal uboot and openwrt sdk
Main advantages
Applicable scenarios
- Long transmission
distance
- High interference
resistance
- Good bypass
- Safe and stable
-Military / public security
- Fire fighting equipment
- Emergency rescue command
- Forest / Mountain
- Coal mine wireless monitoring
- Outdoor power, survey
3. Product Specification
|
RF parameters
|
frequency range
|
802.11AN,5.180G~5.825GHz
|
|
|
modulation mode
|
DSSS/CCK BPSK/QPSK OFDMBPSK/QPSK//16-QAM/64-QAM
|
|
|
Transmit power
|
30dBm
|
|
|
sensitivity
|
-97dBm
|
|
|
RF interface
|
WIFI 2*N
|
|
|
Channel bandwidth
|
5M/10M/20M/40MHz
|
|
|
WiFi
|
5G
|
|
|
Effective distance
|
≥20KM
|
|
Network/management
|
collocation method
|
One-touch
automatic negotiation does not require computer mode or WEB interface computer configuration |
|
|
system
|
MESHCOM
|
|
Physical/Environmental
|
Working
temperature |
-40℃ ~ +65℃
|
|
|
Working humidity
|
5% ~ 95%(non-condensing)
|
|
|
Storage
temperature |
-45ºC ~ +85ºC
|
|
|
weight
|
2.5Kg
|
|
|
size
|
216 x 216 x 70mm
|
|
Electrical
characteristics |
Power supply
|
15V-48V, POE
|
|
|
Support voltage
|
Average power consumption of the whole machine 5W
|
|
Appearance interface
|
Expansion interface
|
N*2
|
|
|
Power interface
|
10M/100M RJ45*1
|
Related Products
Packing&Shipping
Packing: Packed in a professional shipping box
Port: Yantian, Shekou or Hong Kong
Company Introduction
Our R&D team has over 20 years of professional technical experience in design, develop, build, support and delivery ot end-to-end communications&advanced networkings. The company attaches great importance to the construction of the R&D team, with a team who with extensive industry experience and accumulation in the fields of RF communication, Baseband unit, and images processing.
Our products range includes mimo mesh network, tactical radio, software detined radio, tactical data link, ip encoder, there has also been continued demand in the areas of C2/C3/C4ISR/C5ISR mission systems, border and perimeter security systems, unmanned aircraft systems, unmanned surtace vessels, remote controlled systems, and homeland security solutions, law enforcement and also covering film, broadcast and live stream activities that who can't risk communication failure.
