Quick Details
-
Weight (KG):
-
720
-
Voltage:
-
220V/50Hz
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CHLB
-
Dimension(L*W*H):
-
L(4105)*W(2457)*H(3750)mm
-
Name:
-
Vertical Automatic Packaging Machine
-
Model:
-
CB-520PM
-
Bag size:
-
L(100-400)mm/W(100-250)mm
-
Packing material:
-
OPP/CPP,OPP/PE,PET/PE,PE
-
Product contact surface:
-
304 stainless steel
-
Outer screw:
-
Full stainless steel
-
Usage:
-
Food/Snack/Other
-
Packing speed:
-
5-55 Bags/min
-
Control system:
-
PLC+Touch Screen
-
Advantage:
-
Servo Motor Control
Quick Details
-
Function:
-
FILLING, Wrapping, Sealing, counting, Wrapping, Coating
-
Packaging Type:
-
Bags, Film, Pouch
-
Packaging Material:
-
Plastic
-
Weight (KG):
-
720
-
Voltage:
-
220V/50Hz
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CHLB
-
Dimension(L*W*H):
-
L(4105)*W(2457)*H(3750)mm
-
Name:
-
Vertical Automatic Packaging Machine
-
Model:
-
CB-520PM
-
Bag size:
-
L(100-400)mm/W(100-250)mm
-
Packing material:
-
OPP/CPP,OPP/PE,PET/PE,PE
-
Product contact surface:
-
304 stainless steel
-
Outer screw:
-
Full stainless steel
-
Usage:
-
Food/Snack/Other
-
Packing speed:
-
5-55 Bags/min
-
Control system:
-
PLC+Touch Screen
-
Advantage:
-
Servo Motor Control
Factory Price Puff Food Crisp Banana Plantain Chips Snack French Fries Potato Chips Automatic Pouch Packing Machine
|
Model
|
|
CB-520PM
|
|
|
|||
|
Max width of roll film
|
|
≤520mm
|
|
|
|||
|
Bag sizes
|
|
L(100-400)mm/W(100-250)mm
|
|
|
|||
|
Packing speed
|
|
5-55bags/min
|
|
|
|||
|
Packing material
|
|
OPP/CPP, OPP/PE,PET/PE,PE
|
|
|
|||
|
Consumption
|
|
6-8kgf/cm², 0.15m³/min
|
|
|
|||
|
Power and voltage
|
|
AC200V, single phase 50-60Hz, 3.5KW
|
|
|
|||
|
Total weight
|
|
720KG
|
|
|
|||
|
Dimension
|
|
L(4105)*W(2457)*H(3750)mm
|
|
|
|||
Product Features：
PRODUCT DETAILS
APPLICATIONS
COMPANY INFORMATION
PRODUCTION PROCESS
CERTIFICATE
EXHIBITION & CUSTOMER PHOTOS
PACKAGING & SHIPPING
FAQ
Q1: Are you a factory?
A1:
Yes, we established in 1998 as a manufacturing supplier with 25 years experience. We can provide you with professional product packaging solutions.
Q2: What info you need before confirming the machine?
A2:
Your product picture, your product size(length,width,height,weight etc.),packing type(Back seal / quad seal / 3-side seal / 4-side seal etc),your product samples(for testing).
Q3: What is the material of contact food/material parts?
A3:
The contact food/material parts are made of 304# stainless steel. The machine body can be 304# stainless steel or carbon steel.
Q4: Can this machine make different bag sizes?
A4:
One former can make one bag width, and the bag length can be adjustable within a range. It should be ordered an extra former if you want to make the other bag width.
Q5: Does your company accept OEM?
A5:
Yes, we have a professional desig
n and technical team to accept customization.
Q6: When you can deliver the machine after the order is placed?
A6:
We usually can arrange shipment
after 30-40 working days, but it depends on the quantity of the products.
Q7: How about your warranty?
A7:
We provide 13 months
warranty, starts from the issue date of bill of lading.
Q8: What can you provide after service?
A8:
We can provide machine testing
video and pictures before delivery, English manual, some free spare parts, installation in clients' factory and technical
training.
