Quick Details
-
Panel Size:
-
1000*500mm
-
Place of Origin:
-
China
-
Model Number:
-
p8/16
Quick Details
-
Application:
-
Outdoor
-
Brand Name:
-
MDS
-
Color:
-
Full color
-
Panel Size:
-
1000*500mm
-
Place of Origin:
-
China
-
Model Number:
-
p8/16
Product Description
Specification
|
Parameters
|
8/16mm
|
16/16mm
|
16/25mm
|
33/50mm
|
|
|
LED Type
|
SMD(3535)
|
SMD(3535)
|
DIP346
|
DIP346
|
|
|
Pixel configuration
|
SMD3 in 1
|
SMD3 in 1
|
1R1GRB
|
2R2G2B
|
|
|
Pixel pitch(H×W) mm
|
8.33/16.67
|
16.67/16.67
|
16/25
|
33/50
|
|
|
Module size(H×W×L) mm
|
1000×9.5×11
|
1000×9.5×11
|
1000×14.8×18
|
single light strip
|
|
|
Resolution
|
120×30
(H×W)
|
60×30
(H×W)
|
60*20(H×W)
|
30*10(H×W)
|
|
|
Cabinet size(H×W×L）mm
|
1000×500×60
|
1000×500×60
|
1000×500×60
|
1000×500×60
|
|
|
Net. weight/Cabinet
|
7.8kg
|
7.8kg
|
6.8kg
|
7kg
|
|
|
Ingress Protection
|
Front IP65/Rear IP65
|
|
Front IP65/Rear IP65
|
Front IP65/Rear IP65
|
|
|
Power
|
AC 240 or 110±10%,50~60Hz
|
|
AC 240 or 110±10%,50~60Hz
|
AC 240 or 110±10%,50~60Hz
|
|
|
Serviceability
|
Front&Rear service
|
|
Front&Rear service
|
Front&Rear service
|
|
|
Max.Power consumption
|
≤500W/m²
|
≤470W/m²
|
≤450W/m²
|
≤430W/m²
|
|
|
Avg.Power consumption
|
167W/m²
|
157W/m²
|
155W/m²
|
150W/m²
|
|
|
Brightness
|
6500cd/m²
|
6500cd/m²
|
6500-9000cd/m²
|
6500cd/m²
|
|
|
Pixel density(pixel/m²）
|
7,200
|
3,600
|
2400
|
600
|
|
|
Viewing Angle(H/V)
|
120°/120°
|
|
120°/60°
|
120°/60°
|
|
|
Contrast ratio
|
3,000:1
|
|
3,000:1
|
3,000:1
|
|
|
Transparency
|
43%
|
|
60%
|
80%
|
|
|
Operation temperature/humidity
|
-30°C to +50°C/10% to 95%
|
|
-30°C to +50°C/10% to 95%
|
-30°C to +50°C/10% to 95%
|
|
|
Lifetime(50%brightness)
|
80,000hours
|
|
80,000hours
|
80,000hours
|
|
|
Gray scale
|
14 bit
|
|
14 bit
|
14 bit
|
|
|
Refresh rate
|
≥1920Hz
|
|
≥1920Hz
|
≥1920Hz
|
|
|
Frame rate
|
30/50/60fps
|
|
30/50/60fps
|
30/50/60fps
|
|
Packing & Delivery
Flight case / wooden case
