Product Overview

Telescopic Type Single Acting Hydraulic Cylinder For Dump Truck

Hydraulic cylinders are usually composed of main parts such as rear end cover, cylinder barrel, piston rod, piston assembly, and front end cover; There is a sealing device between the piston rod, the piston and the cylinder barrel, the piston rod and the front end cover, and a dustproof device is installed outside the front end cover; in order to prevent the piston from hitting the cylinder cover when it quickly returns to the stroke end, the hydraulic cylinder end There is also a buffer device at the end; sometimes an exhaust device is also required.

FEATURES AT A GLANCE

1.Capable of withstanding very high loads

2. Effectively prolong the service life

3. Widely used in various models

4. Simple structure, easy to install

5.Good stability and performance, save unnecessary trouble

6. A wide range of cylinders can be ordered in any size and material

7. Using high-quality raw materials, in line with European standards, German standards, American standards, national standards ertification standards

8. Quality assurance short delivery time, lifelong after-sales service, complete production line

Cylinder block

Piston and piston rod

Cylinder accessories

PRODUCT SPECIFICATIONS

Mechanical properties
Steel grade	tensile strength (бb N/mm2)	Yield strength (бs N/mm2)	Elongation (δ%)	Hardness (HB)
20#	≥520	≥470	≥12	175
45#(CK45)	≥600	≥520	≥12	207
16Mn(ST52)	≥600	≥520	≥12	190
25Mn	≥600	≥510	≥15	195
27SiMn	≥800	≥720	≥10	230

Product Description
Processing form	Cylinder ID (mm)	length (m)	Straingtness (mm/m)	Tolerance on ID	Roughness (µ/m)
Cold drawn	30-250	≤13m	0.2-0.5	H9-H11	0.8-1.6
Precision rolling	40-800	≤13m	0.2-0.3	H7-H9	0.2-0.4
Honing	40-800	≤7m	0.2-0.3	H7-H9	0.4-0.8
Burnished	40-400	≤7m	0.2-0.3	H8	≤0.4

Dimension Tolerence

Size of ID (mm)

ID Tolerance

Tolerance of wall thickness

H10

H11

+0.021

+0.033

+0.052

+0.084

+0.130

±5%

>30-50

+0.025

+0.039

+0.062

+0.100

+0.160

50-80

+0.030

+0.046

+0.074

+0.120

+0.190

80-120

+0.035

+0.054

+0.087

+0.140

+0.220

120-180

+0.040

+0.063

+0.100

+0.160

+0.250

180-250

+0.046

+0.072

+0.115

+0.185

+0.290

250-315

+0.052

+0.081

+0.130

+0.210

+0.320

315-400

+0.057

+0.089

+0.140

+0.230

+0.360

Product Type

Muti-Stage cylinder	1.Cylinder material adopts CK45 or materials withe quivalent strength, with large safety margin
		2.The sealing ring is imported from abroad to ensure quality
		3.The parts are processed by CNC machine tools, the precision is easy to be effectively guaranteed, and the quality consistency is good

Dump truck cylinder	1.Use high-end 3D software to design the cylinder and check the strength of key parts of the cylinder
		2.Equipped with a cylinder laboratory, each cylinder is tested at the factory
		3.Conduct empty and full load performance test and life test to ensure quality
		4.Cylinder has sufficient strength and rigidity

Tractor cylinder

Steering Cylinder

Larger Hydraulic Cylinder

Cron Harvest Cylinder

Excavator Cylinder

Loader Cylinder

Garbage Truck Cylinder

Outrigger Cylinder

Semi-trailer rollover Cylinder

Agricultural machinery cylinder

Dump Lifting Cylinder

Section cup Lift Cylinder

Oil press Cylinder

Marine Hydraulic Cylinder

Lift Cylinder

Manufacturing Technique

Our design and R&D team will use high-end 3D design software and simulation software to design the cylinder, and make 3D and 2D drawings in strict accordance with the requirements of each customer. After careful inspection and observation, they will be distributed to the workshop. The processing workers start to make products, and then they will conduct inspections, assessments, and tests in the corresponding areas. When all product performance, strength, hardness, and rigidity requirements are fully met by customers, they will be packaged and put into storage, waiting for delivery;

Workshop and Product line

We have ourselves product equipment,and every steps all have seperate areas,such as cutting areas,bored areas,lathe areas,CNC machine areas,Honed areas,burnished areas,welding areas,straight areas,measuring areas, mounted areas,finished surface areas,storage areas,etc.

We have complete product line,our workers all are work more than 10years in our factory,our technical team are so strong,and warranty all customer requirement;

Hydraulic Cylinder drawing and some parameter

This drawing just show a few type hydraulic cylinders, we can make any size and materials cylinders,If you want to customization,that's all no problem,you can send us your drawing or your sample ,we can as your require to do ;

63x35x500 Type hydraulic Cylinder drawing To Show

This drawing just show a few type hydraulic cylinders, we can make any size and materials cylinders,If you want to customization ,that's all no problem,you can send us your drawing or your sample ,we can as your require to do ;

Telescopic type hydraulic cylinder drawing

Rack Piston Hydraulic Cylinder

Double Act piston rod hydraulic cylinder drawing

Rack piston hydraulic cylinder structure drawing

Hydraulic Cylinder Assembly drawing

Double-acting hydraulic cylinder application circuit
