Quick Details
-
Model Number:
-
FAMS1002-01
-
Material:
-
Plastic
-
Product name:
-
automatic electric mist sprayer
-
Color:
-
green Black
-
Application:
-
Garden
-
Capacity:
-
26L/H 28L/H 30L/H 32L/H
-
Nozzle:
-
Four Nozzles
-
Size:
-
54*35*28cm
-
Certification:
-
ISO9001
Quick Details
-
Sprayer Type:
-
Trigger
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
DFS
-
Model Number:
-
FAMS1002-01
-
Material:
-
Plastic
-
Product name:
-
automatic electric mist sprayer
-
Color:
-
green Black
-
Application:
-
Garden
-
Capacity:
-
26L/H 28L/H 30L/H 32L/H
-
Nozzle:
-
Four Nozzles
-
Size:
-
54*35*28cm
-
Certification:
-
ISO9001
Feature
l This series can be equipped with different flow rates and spray diameters micro sprinklers. It can achieve saving water, saving fertilizer and saving energy.
l The micro-sprinkler assembly is made of high-quality materials that are resistant to UV and atmospheric chemicals, ensuring maximum accuracy and longevity.To meet needs, micro- sprinkler c omponents can be replaced .
l Micro sprinklers are ideal for small-flow irrigation equipment for vegetables, orchards, landscaping, greenhouses, nurseries, cooling, frost protection and yard irrigation.
Technical P arameter
|
Working pressure |
150Kpa |
200Kpa |
250Kpa |
300Kpa |
|||||||
|
Production |
Item No. |
Nozzle color |
Nozzle dia (mm) |
Flow rate (L/h) |
Spray radius (m) |
Flow rate (L/h) |
Spray radius (m) |
Flow rate (L/h) |
Spray radius (m) |
Flow rate (L/h) |
Spray radius (m) |
|
Refraction atomized micro sprinkler |
RAMS1001 |
Black |
0.8 |
24.6 |
upside down: 0.8 Plug: 0.8 |
28.7 |
upside down: 0.8 Plug: 0.8 |
31.6 |
upside down: 0.9 Plug: 0.9 |
34.9 |
upside down: 0.9 Plug: 0.9 |
|
RAMS1002 |
Blue |
1.0 |
39.7 |
upside down: 1.0 Plug: 0.9 |
44.9 |
upside down: 1.0 Plug: 0.9 |
50.0 |
upside down: 1.1 Plug: 1.0 |
55.6 |
upside down: 1.1 Plug: 1.1 |
|
|
RAMS1003 |
Green |
1.2 |
58.5 |
upside down: 1.1 Plug: 1.0 |
66.6 |
upside down: 1.1 Plug: 1.0 |
75.0 |
upside down: 1.2 Plug: 1.1 |
89.5 |
upside down: 1.2 Plug: 1.2 |
|
|
RAMS1004 |
Red |
1.6 |
73.5 |
upside down: 1.2 Plug: 1.0 |
86.1 |
upside down: 1.2 Plug: 1.1 |
98.3 |
upside down: 1.3 Plug:1.2 |
110.7 |
upside down: 1.4 Plug: 1.2 |
|
Note: The spray radius is measured at a height of 0.9 m above the ground and 1.8 m at the time of inversion when the outdoor wind is free of wind. The radius is the distance from the center point of the micro-sprinkler with the normally installed and the sprayed wet ground farthest away.
| Pic | Item No. | Description | Packing (Pcs) | Measurement (Cm) | G.W (Kgs) |
|
FAMS1001 | Four Outlet Atomizing Micro Sprinkler,Green | 100/1000 | 54*35*28 | 8 |
| FAMS1002 | Four Outlet Atomizing Micro Sprinkler,Grey | 100/1000 | 54*35*28 | 8 | |
|
FAMS1003 | Four Outet Atomizing Micro Sprinkler,Black | 100/2500 | 54*35*28 | 20 |
| FAMS1004 | Four Outlet Atomizing Micro Sprinkler,Grey | 100/2500 | 54*35*28 | 20 |
