Quick Details
-
Panel Size:
-
66*16.4*6.7mm
-
Place of Origin:
-
Zhejiang, China
-
Model Number:
-
16x80 display
-
Pixel Pitch:
-
7.62mm
-
Color Depth:
-
RGB
-
View Angle（H/V）:
-
H: 85 V: 85
-
Pixels:
-
16x80
-
Message Input:
-
Remote Control or PC message entry
-
Applicable Places:
-
Industrial, Indoor
-
Certification:
-
CE, RoHS
-
Warranty:
-
1 Year
-
Material:
-
Aluminum Alloy
-
Standard of Plug:
-
US/UK/Europe/Japan/Australia
-
Power Supply:
-
AC110-250V 50-60Hz, DC 5V
-
External Battery Supply:
-
Accept
-
Installation:
-
Wall Mounting, Ceiling
Quick Details
-
Application:
-
Indoor
-
Type:
-
LED
-
Brand Name:
-
Jhering
-
Panel Size:
-
66*16.4*6.7mm
-
Place of Origin:
-
Zhejiang, China
-
Model Number:
-
16x80 display
-
Pixel Pitch:
-
7.62mm
-
Color Depth:
-
RGB
-
View Angle（H/V）:
-
H: 85 V: 85
-
Pixels:
-
16x80
-
Message Input:
-
Remote Control or PC message entry
-
Applicable Places:
-
Industrial, Indoor
-
Certification:
-
CE, RoHS
-
Warranty:
-
1 Year
-
Material:
-
Aluminum Alloy
-
Standard of Plug:
-
US/UK/Europe/Japan/Australia
-
Power Supply:
-
AC110-250V 50-60Hz, DC 5V
-
External Battery Supply:
-
Accept
-
Installation:
-
Wall Mounting, Ceiling
Product Parameter
|
Model
|
16x80 display
|
|
|
Dimension
|
66 x 16.4 x 6.7 cm
|
|
|
Digital Height
|
5.4 cm+11.5 cm
|
|
|
Character Color
|
RED+GREEN 2 grays 11 color combination Characters. No Blue Color !!!.
|
|
|
Pixels
|
16x80
|
|
|
Max. Viewing Distance
|
100ft
|
|
|
Pitch
|
7.62 mm
|
|
|
Dot Diameter
|
Round, 5mm
|
|
|
Viewing Angle(degrees)
|
H:85 V:85
|
|
|
Lines
|
1 line
|
|
|
Brightness
|
858nts
|
|
|
LED Lifetime Rating
|
70,000 hours
|
|
|
Message Input
|
Remote Control or PC message entry
|
|
|
Message Capacity
|
100 different messages can be stored and displayed
|
|
|
Sign Memory
|
512k bytes.
|
|
|
Memory Retention:
|
10 years
|
|
|
Message Presentation Modes
|
26
|
|
|
Real-Time Clock
|
Date and time, 12 or 24 hour format, maintains accurate time without power for up to 30 days typical
|
|
|
Operation Temperature
|
32° to 158 °F, (0° to 70 °C)
|
|
|
Humidty Range
|
0% to 95% non-condensing
|
|
|
Power Cord Length
|
1.5m
|
|
|
Power Supply
|
AC110-250V 50-60Hz, DC 5V(Default), 12V, 24V
|
|
|
Optional communication ways
|
RS232(Default), RS485, USB, TCP/IP, Wireless, GSM, GRPS, WIFI.
|
|
|
NOTE:
|
|
|
|
1. Not provide the software&manual CD, Please download from our web site.
|
|
|
|
2. Software only supports Windows system. And we provided the led sign protocol, support develop your own applications.
|
|
|
|
3. The software is safe, No virus, our all of led sign use this software, and some led sign use network(TCP/IP) or GRPS, so the software will visit network, some Anti-virus software will alarm it,just ignore it.
|
|
|
|
|
|
|
