500x500 Full color outdoor indoor led display screen panel p2.6 p2.97 p2.9 p3.91 p3.9 p4.8 p4.81 2.9mm 3.9mm 4.8mm

500x500 Full color outdoor indoor led display screen panel p2.6 p2.97 p2.9 p3.91 p3.9 p4.8 p4.81 2.9mm 3.9mm 4.8mm

FOB Reference Price: Get Latest Price

≥1 Pieces

US $89

≥50 Pieces

US $80.1

≥100 Pieces

US $71.2

≥1000 Pieces

US $41

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Panel Size:: 500x500mm

Place of Origin:: Guangdong, China

Model Number:: 500x500mm

Pixel Pitch:: P2.97/P3.91/P4.81, P2.97/P3.91/P4.81

Tube Chip Color:: FULL COLOR

Usage:: LED DISPLAY

Display Function:: Videos, pictures, words

Pixels:: P2.97/P3.91/P4.81

Power Supply:: 200-300w

Control system:: Novastar or other option

Input Voltage:: AC110V - AC240V

Packaging:: Flight case or wooden case

Warranty:: 2 years

Cabinet size:: 500x500

Quick Details

Application:: Stage background led screen

Brand Name:: Eagerled

Color:: full color

Panel Size:: 500x500mm

Place of Origin:: Guangdong, China

Model Number:: 500x500mm

Pixel Pitch:: P2.97/P3.91/P4.81, P2.97/P3.91/P4.81

Tube Chip Color:: FULL COLOR

Usage:: LED DISPLAY

Display Function:: Videos, pictures, words

Pixels:: P2.97/P3.91/P4.81

Power Supply:: 200-300w

Control system:: Novastar or other option

Input Voltage:: AC110V - AC240V

Packaging:: Flight case or wooden case

Warranty:: 2 years

Cabinet size:: 500x500

Product Description

Why choose our products？？

◎Front & Rear Double Maintenance Design
◎Easy & Fast Installation ◎Curve Lock Design (-10° to +10°)
◎Can Curved Installation
◎IP65 Dustproof And Waterproof
◎Viewing angle is up to 120° vertical and horizontal

500x500mm Rental LED panel Specification

Model : EA500H1

Pixel pitch : 2.6/2.97/3.91/4.81mm

Weight : 7kg

Refresh Rate: >1920Hz/>3840Hz

Gray Scale: 14bit +/-

Control system : Novastar

Voltage: 110-230V

Connection from card to modules: Hub verbsion , quick replacement

Maintenance way: both front and rear

Curved screen option : Yes.

Cabinet Corner protection option : Yes.

Outdoor 500x500mm Rental LED Display EA500H1 Series Parameter
Pixel Pitch (mm)	P2.97	P3.91	P4.81
Pixel Configuration	SMD1415	SMD1921	SMD1921
Density (Pixels/㎡)	112896	65536	43264
Module Resolution (Pixel)	84x84	64x64	52x52
Module Size (mm)	250x250	250x250	250x250
Driving Mode (Duty)	44582	44577	44574
Cabinet Size (mm)	500x500	500x500	500x500
Cabinet Weight (KG)	7	7	7
Brightness (CD/㎡)	≥5,000	≥6,000	≥6,000
Viewing Angle (°)	120	120	120
Gray Grade (Bits)	14	14	14
Operation Power	AC100-240V 50-60Hz	AC100-240V 50-60Hz	AC100-240V 50-60Hz
Max. Power Consumption (W/㎡)	720	720	560
Avg. Power Consumption (W/㎡)	240	240	190
Frame Frequency (Hz)	≥60	≥60	≥60
Refresh Frequency (Hz)	≥3,840	≥3,840	≥3,840
Working Temperature (℃)	-20～+60	-20～+60	-20～+60
Lifetime (Hours)	100000	100000	100000
Protection Grade	IP65(front), IP54(rear)	IP65(front), IP54(rear)	IP65(front), IP54(rear)
Indoor 500x500mm Rental LED Display EA500H1 Series Parameter
Pixel Pitch (mm)	P2.6	P2.97	P3.91	P4.81
Pixel Configuration	SMD1515	SMD2020	SMD2020	SMD2020
Density (Pixels/㎡)	147456	112896	65536	43264
Module Resolution (Pixel)	96x96	84x84	64x64	52x52
Module Size (mm)	250x250	250x250	250x250	250x250
Driving Mode (Duty)	1/32	44589	44577	44574
Cabinet Size (mm)	500x500	500x500	500x500	500x500
Cabinet Weight (KG)	6.5	6.5	6.5	6.5
Brightness (CD/㎡)	≥1,200	≥1,000	≥1,000	≥1,000
Viewing Angle (°)	120	120	120	120
Gray Grade (Bits)	14	14	14	14
Operation Power	AC100-240V 50-60Hz	AC100-240V 50-60Hz	AC100-240V 50-60Hz	AC100-240V 50-60Hz
Max. Power Consumption (W/㎡)	480	480	576	560
Avg. Power Consumption (W/㎡)	160	160	192	190
Frame Frequency (Hz)	≥60	≥60	≥60	≥60
Refresh Frequency (Hz)	≥3,840	≥3,840	≥3,840	≥3,840
Working Temperature (℃)	-20～+60	-20～+60	-20～+60	-20～+60
Lifetime (Hours)	100000	100000	100000	100000
Protection Grade	IP31	IP31	IP31	IP31
