Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
LEHMAN/ OEM
-
Voltage:
-
0
-
Dimension(L*W*H):
-
Customized Size
-
Weight (KG):
-
3 kg
-
Model Number::
-
EP80~EP500, NN80~NN500
-
Fabric::
-
Cotton(CC),Polyster (EP), Nylon(NN)
-
Fabric Tensile Strength::
-
80~500 Per Ply
-
Material Feature::
-
Heat/ Cold/ High Temperature/ Oil/ Chemical Resistant
-
Ply Thickness(mm/p)::
-
0.8-1.5 mm
-
Top Cover Thickness(mm)::
-
0-12 mm
-
Lower Cover Thichness(mm)::
-
0-4.5 mm
-
Width Range::
-
100-2500mm
-
Length:
-
5M~500M Per Roll
-
Quality Standards::
-
GB/T7984-2001, DIN22102 ,RMA,AS1332, JISK6322
Quick Details
-
Power:
-
0
-
Warranty:
-
3 months
-
Width or Diameter:
-
Other
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
LEHMAN/ OEM
-
Voltage:
-
0
-
Dimension(L*W*H):
-
Customized Size
-
Weight (KG):
-
3 kg
-
Model Number::
-
EP80~EP500, NN80~NN500
-
Fabric::
-
Cotton(CC),Polyster (EP), Nylon(NN)
-
Fabric Tensile Strength::
-
80~500 Per Ply
-
Material Feature::
-
Heat/ Cold/ High Temperature/ Oil/ Chemical Resistant
-
Ply Thickness(mm/p)::
-
0.8-1.5 mm
-
Top Cover Thickness(mm)::
-
0-12 mm
-
Lower Cover Thichness(mm)::
-
0-4.5 mm
-
Width Range::
-
100-2500mm
-
Length:
-
5M~500M Per Roll
-
Quality Standards::
-
GB/T7984-2001, DIN22102 ,RMA,AS1332, JISK6322
Quality assurance pvc belt conveyor / pvc conveyor belt price .
Features:
1)Polyester (EP) conveyor belt, the tension resistant body, which is canvas woven by polyester in warp and polyamine in weft. The belts have the characteristics of good impact resistance, good water resistance, as well as the strength remaining unchanged in wet status, wihtout going mouldy.
According to structure, It can be divided into tow types : Molded edge (Mould edge) & Cut edge
2)Nylon(NN) conveyor belt:It is characterized by thin belt tody,light weight,good elasticity and impact resistance ,good troughability .The product widely used in quarry,iron ore & copper mines etc,where requiring medium,long distance conveying,high-speed and heavy-load transportation of materials.
Colors: black
Usage: Widely used in coal,mining ,cement ,power,chemical,metallurgy,construction,port and other transportation materials industry and places.
General conveyor belt
| General conveyor belt technical parameters | ||||||
| Belt type | Fabric type | Strength per ply | Cover thickness(mm) | Fabric ply | Width (mm) | |
| Tpo cover | Bottom cover | |||||
| Nylon(NN) | NN100 | 100 | 2.0-8 | 0-4.5 | 2-10 | 300-2800 |
| NN125 | 125 | |||||
| NN150 | 150 | |||||
| NN200 | 200 | |||||
| NN250 | 250 | |||||
| NN300 | 300 | |||||
| NN400 | 400 | |||||
| NN500 | 500 | |||||
| Polyester(EP) | EP100 | 100 | 2-8 | 300-2800 | ||
| EP125 | 125 | |||||
| EP150 | 150 | |||||
| EP200 | 200 | |||||
| EP250 | 250 | |||||
| EP300 | 300 | |||||
| EP400 | 400 | |||||
| EP500 | 500 | |||||
|
Brand Name: |
LEHMAN, OEM |
| Model Number: | EP80~EP500, NN80~NN500 |
| Fabric: | Cotton(CC),Polyster (EP), Nylon(NN) |
| Fabric Tensile Strength: | 80~500 Per Ply |
| Material Feature: | Heat/ Cold/ High Temperature/ Oil/ Chemical Resistant |
| Ply Thickness(mm/p): | 0.8-1.5 mm |
| Top Cover Thickness(mm): | 0-12 mm |
| Lower Cover Thichness(mm): | 0-4.5 mm |
| Width Range: | 100-2500mm |
| Length | 5M~500M Per Roll |
| Quality Standards: | GB/T7984-2001, DIN22102 ,RMA,AS1332, JISK6322 |
| Certificate: | ISO9001:2008,CAS |
| Edge: | Molded edge / Cut edge |
| Color: | Black, White |
| Rubber tensile strength: | 6Mpa~24Mpa |
| temperature range | -65C° ~ 1000 C° |
