Quick Details
-
Interface Standard:
-
IEC-61851, IEC62196, Type 2
-
Output Current:
-
AC
-
Input Voltage:
-
220V+/-15% 240V+/-15%
-
Product name:
-
AC Fast Charging Station EV Portable Wall-mounted Charger Pile
-
Power:
-
7kw
-
Screen size:
-
Friendly interaction interface, 4.3 inches color touch screen
-
Communication:
-
3G/4G/WiFi/Enthernet or wireless telecommunication
-
Applicable Scenes:
-
Provide charging for private cars, commuter, bus, taxi
-
Product feature:
-
Simple operation, convenient installation;
-
Car Fitment:
-
TOYOTA,Volvo,Cadillac,WEY,MINIEV, telsa, byd, audi, bmw
-
connector or plug type:
-
America, Europe, China, and Japan standard option
-
Our support:
-
Our products support customization. Also support OEM, ODM.
-
Warranty:
-
24months without human damage, 3 years, 4 years , 5 years option
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
ACL007A
-
Brand Name:
-
starlight or your brand
-
Interface Standard:
-
IEC-61851, IEC62196, Type 2
-
Output Current:
-
AC
-
Input Voltage:
-
220V+/-15% 240V+/-15%
-
Product name:
-
AC Fast Charging Station EV Portable Wall-mounted Charger Pile
-
Power:
-
7kw
-
Screen size:
-
Friendly interaction interface, 4.3 inches color touch screen
-
Communication:
-
3G/4G/WiFi/Enthernet or wireless telecommunication
-
Applicable Scenes:
-
Provide charging for private cars, commuter, bus, taxi
-
Product feature:
-
Simple operation, convenient installation;
-
Car Fitment:
-
TOYOTA,Volvo,Cadillac,WEY,MINIEV, telsa, byd, audi, bmw
-
connector or plug type:
-
America, Europe, China, and Japan standard option
-
Our support:
-
Our products support customization. Also support OEM, ODM.
-
Warranty:
-
24months without human damage, 3 years, 4 years , 5 years option
Moveable 7kw AC type1/2 Fast Charging Station EV Portable Wall-mounted Charger Pile
Electric ac fast charging station are the indispensable energy service infrastructures of electric vehicles after large-scale industrialization of electric vehicles. In order to meet the national demand for the development of new energy electric vehicles and accelerate the construction of new energy electric vehicle infrastructures, our company has rapidly developed a series of electric vehicle charging station supporting products.
The system of AC wall mounted charger pile are formed by three parts: system software of charging station , AC charging system and DC charging system. That is, DC charging system is composed of charger, monitoring device of charger and DC charger; AC charging system is composed of several AC chargers.
The system of charging stations for fast ev charger pile mainly has realized the functions of background monitoring, high voltage DC charging, AC charging, charging monitoring, charge metering, security monitoring, battery maintenance monitoring, data exchange and forwarding. The distributed design is adopted, which has the characteristics of safety, reliability, convenience and easy maintenance.
Specification:
|
S. NO. |
Parameters |
Requirements |
|
General Requirements |
||
|
1 |
Charger Capacity |
7KW Electric AC EV charger |
|
2 |
Model No. |
ENC-ACL007A |
|
Input Requirements |
||
|
3 |
AC Supply System |
Single-Phase, 3 Wire AC system |
|
4 |
Nominal Input voltage |
AC220V±15% |
|
5 |
Input frequency |
50/60±3Hz |
|
Environmental Requirements |
||
|
6 |
Ambient Temperature Range |
-20 to 55°C |
|
7 |
Ambient Humidity |
5 to 95% |
|
8 |
Storage temperature |
-40 to 70°C |
|
Mechanical Requirements |
||
|
9 |
IP Ratings |
IP 54 |
|
10 |
Cooling |
Natural Cooling |
|
Output Requirements |
||
|
11 |
Number of outputs |
1 |
|
12 |
Type of each output |
Single phase:AC220V±15% , 32A. |
|
13 |
Single Output Current |
Max.32Amp |
|
14 |
Output Connector Compatibility |
IEC-61851, IEC62196, Type 2 |
|
15 |
Connector Mounting |
Indoor/Outdoor use |
|
User Interface & Display Requirements |
||
|
16 |
Emergency stop switch |
Support |
|
17 |
Display |
4.3’’ touch screen |
|
18 |
User Authentication |
RFID Card /Password Login |
|
19 |
Metering Information |
Consumption Units |
|
Communication Requirements |
||
|
20 |
Communication between EVSE and Central Server |
OCPP 1.6J protocol |
|
21 |
Metering |
Grid responsive metering as per units’ consumption of each vehicle |
|
22 |
Interface between charger and CMS |
Ethernet/3G/4G (Optional) |
|
Protection & Safety Requirements |
||
|
23 |
Safety Parameters |
Over current, under voltage, Residual current, Surge protection, leakage protection, Short circuit, Over temperature, etc. |
|
Others |
||
|
24 |
Device dimension(mm) |
L340*W201*H1500 |
|
25 |
Gross weight (kg) |
About 57.5kg |
Features:
- Installation: Ground mounted;
- AC220V±15% Voltage input;
- The MCU with embedded operating system is used in the main control board. The charging mode is divided into four types: automatic filling, fixed time, fixed amount and fixed power. It can reserve RS-485 networking communication interface and provide GPRS networking mode.
- 4.3-inch 480x272 color touch screen is used to display the charging mode, which can be operated by touching keys.
- Three-phase electronic watt-hour meter is used to measure electricity and communicate with the main control board through RS-485 interface.
- A contactless smart card reader is used to read the relevant information of IC card and communicate with the main control board through RS-485 interface. The background program of the main control board is used to identify the user, record user information and calculate charging costs.
- The incoming switch with leakage protection function and the emergency stop button is installed.
- The housing is made of sheet metal.
Applicable Scenes:
Charging Station of electric vehicles in large, medium and small scales;
Various public places with parking spaces for electric vehicles, such as urban residential areas, shopping plazas, power business places, etc.
High-speed service area, station terminal and other transport hub areas.
VARIOUS VERSIONS
The best charging experience for drivers
Intelligent temperature comtrol system
10 Safety protection systerm
Car AC charging pile Solution
Installation Method
Sample can send by DHL/UPS/FEDEX/EMS OR AIR/SEA shipping. Generally, we pack our goods in neutral brown cartons.
