Spray application 1k 2k auto xylene paint for car refinish

Characteristic

The paint is made by several durability - improved resins , high quality and good coverage . The base paint can be blended to optimum metallic , solid or pearl color effects . Its excellent adhesion and interlayer adhesion for the physical properties of finishing varnishes .

Applicable base materials

Existing paint that have been de-greased and sanded with #1000 sand paper in wet , 1020R and 1K intermediate paints coat on surface of primer .

S urface Cleaning

Degreasing cleaning agent, silicone materials and other impurities

Mixing ratio

10 - 25°C

Above 25°C

1K basecoate : 100 portions ;

AB380 Primer paint thinner

AK321 general thinner :80 -100 portions

1K basecoat : 100 portions

AK321 General thinner

AK322 Slow-drying thinner : 80 - 100 portions

Serviceable time

24 hours , 20 °C

Spray Layers

2-3 layers,50-75um total thickness

Interval

5-10mins,20°C

Spray gun & Pressure

Gravity Feed Spray Gun 1.2-1.5mm 3-5kg/cm2
Suction Feed Spray Gun 1.4-1.7mm 3-5kg/cm2

Characteristic

Tinter for two-component , it is singel-layer 2K pure-color paint for high-grade automobile body repairment . Paint layer fullness and hardness . Color retention of paint layer and bright ; It is excellent protection and coverage , good heat and water resistance , strong adhesion . Use with AK260 curing agent .

Applicable base materials

It applies to thoroughly ground and cleaned intermediate paints ( incl wet to wet prcess ) , original paint or intact 2K paint surface , and soft base materials with an insulating layer .

S urface Cleaning

Degreasing cleaning agent, silicone materials and other impurities

Mixing ratio

12 - 18°C

2K pure-color paint:100 portions

AK260 quick-drying drier : 50 portions

AK321 General thinner : 10-20 portions

18 - 24°C

2K pure-color paint:100 portions

AK260 standard drier:50 portions

AK321 General thinner:10-20 portions

25 - 30 °C

2K pure-color: 100 portions ;

Ak260 standard drier:50 portions

AK322 slow-drying thinner :10 - 20 portions

30 - 40 °C

2K pure-color paint: 100 portions

AK260 slow-drying drier:50 portions

AK323 extremely slow-drying thinner:10 - 20 portions

Serviceable time

AK260(quick-drying) : 2 hours , 20 °C

AK260 standard or AK260(slow-drying):4 hours , 20 °C

Spray and applying Layers

2-3 layers,50-70um in total

Interval

5-10mins,20°C

Spraying and applying tool

Geocentric Spray Gun ( upper bottle ) 1.2-1.5mm , 3-5kg/cm2

Suction spray gun ( lower bottle ) 1.4-1.7mm ,3-5kg/ cm2
