Quick Details
-
Max. Loading Capacity:
-
300L
-
Weight (KG):
-
200 KG
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Promake
-
Voltage:
-
415V , 3 phase , 50Hz(customizable)
-
Dimension(L*W*H):
-
depend on capacity
-
Power (kW):
-
16.1 kW
-
Marketing Type:
-
New Product
-
Product name:
-
Mixing Tank
-
Heating method:
-
Electric heating
-
After Warranty Service:
-
Video technical support
-
Advantage:
-
Easy Operation High Efficiency
-
Motor:
-
16.1kw
-
Jacket:
-
Heating Jacket Avaible
-
Certification:
-
CE
-
Capacity:
-
300L
-
Stirrer type:
-
Wall Scraper Mixer
Quick Details
-
Barrel Volume (L):
-
100
-
Max. Loading Volume (L):
-
100 L
-
Range of Spindle Speed(r.p.m):
-
0 - 63 r.p.m
-
Max. Loading Capacity:
-
300L
-
Weight (KG):
-
200 KG
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Promake
-
Voltage:
-
415V , 3 phase , 50Hz(customizable)
-
Dimension(L*W*H):
-
depend on capacity
-
Power (kW):
-
16.1 kW
-
Marketing Type:
-
New Product
-
Product name:
-
Mixing Tank
-
Heating method:
-
Electric heating
-
After Warranty Service:
-
Video technical support
-
Advantage:
-
Easy Operation High Efficiency
-
Motor:
-
16.1kw
-
Jacket:
-
Heating Jacket Avaible
-
Certification:
-
CE
-
Capacity:
-
300L
-
Stirrer type:
-
Wall Scraper Mixer
Attention：
1. All prices and parameters shown above are nonstandard. If you want to know more information, please click "Contact
Supplier" to send us an email.
2.
Due to time lag difference, we suggest that you can choose to send us an inquiry in Alibaba.com,or email us.
3. When sending us an inquiry or message, please tell us your email or WhatsApp /
WeChat, etc. so that our sales manager can quickly communicate with us You get in touch.
Product Paramenters
|
Design volume:
|
360L
|
|
working volume
|
300L
|
|
Scraper mixer
|
Power:1.1KW, 0-63RPM,
|
|
Impeller mixer
|
Power:3KW, Speed 0-960/min,
|
|
Heating and cooling method:
|
electric heating(6KW*2), the interlayer can also be cooled by water
|
|
Operational condition
|
Atmospheric
|
|
Jacket operating pressure:
|
0.25MPa
|
|
Speed
|
0-63 r/min
|
|
Inner pot material
|
SUS316L
|
|
Frame, hand rail,legs
|
SUS304
|
|
Electric power
|
415V,50HZ, 3 phases
|
Application
1. Daily Chemical & Cosmetics Industry:
such as baby cream, skin cream face cream, shaving cream, toothpaste, cold cream, sunscreen cream,face cleanser, moisture cream, detergent, shampoo etc;
2. Food Industry:
Sauce, cheese, nutrition, infant food, chocolate, sugar , ketchup , mayonnaise, peanut butter, hot sauce peanut oil
and so on
;
3. Chemical Industry:
Latex, sauce, paints, coatings, resins, adhesives, lubricants
, emulsions, ointments, syrup, liquid. etc;
Details Images
Features:
1.
The material of contacted part is
SUS316L
stainless steel, inside and outside of the equipment are with mirror
polishing and GMP standard.
2
. All pipelines and parameter are controlled automaticlly. and the electric appliances which are from world -famous brands
,like Siemens ,Schneider or ABB and so on.
4.Emulsifying tank adopts three-lever stirring system , and during the emulsification ,the whole processing is under a vacuum environment, so it not only can eliminate foam, which created in the emulsification processing ,but also can avoid the unnecessary pollution.
