- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Vmaxpower
-
Model Number:
-
SunINVM 5K MPPT
-
Input Voltage:
-
48VAC
-
Output Voltage:
-
230VAC
-
Output Current:
-
10A-30A
-
Output Frequency:
-
50/60Hz
-
Size:
-
520*370*190mm
-
Certificate:
-
CE/RoHS/ISO 9001/ISO 14001
-
Warranty:
-
2 Years
-
Weight:
-
40.0kgs
-
Rated Power:
-
5000 watts
-
Rated Voltage:
-
230VAC
-
PV Array MPPT Voltage:
-
150VDC
-
Max Charging Current:
-
60Amp
-
Power factor:
-
1.0
-
Control Mode:
-
MPPT Control
-
Inverter type:
-
Hybrid Solar Power Inverter
-
Output waveform:
-
Pure Sine Wave Output
-
Application:
-
Solar Power System Home
-
Protection:
-
Short Circuit Overload Overvolt Overtemp
Quick Details
-
Output Type:
-
Single
-
Type:
-
DC/AC Inverters
-
Inverter Efficiency:
-
93%
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Vmaxpower
-
Model Number:
-
SunINVM 5K MPPT
-
Input Voltage:
-
48VAC
-
Output Voltage:
-
230VAC
-
Output Current:
-
10A-30A
-
Output Frequency:
-
50/60Hz
-
Size:
-
520*370*190mm
-
Certificate:
-
CE/RoHS/ISO 9001/ISO 14001
-
Warranty:
-
2 Years
-
Weight:
-
40.0kgs
-
Rated Power:
-
5000 watts
-
Rated Voltage:
-
230VAC
-
PV Array MPPT Voltage:
-
150VDC
-
Max Charging Current:
-
60Amp
-
Power factor:
-
1.0
-
Control Mode:
-
MPPT Control
-
Inverter type:
-
Hybrid Solar Power Inverter
-
Output waveform:
-
Pure Sine Wave Output
-
Application:
-
Solar Power System Home
-
Protection:
-
Short Circuit Overload Overvolt Overtemp
Product Description
Product Details
Specification
|
Model No.
|
|
SuninvM MPPT 5KW 48V
|
SuninvM MPPT 6KW 48V
|
SuninvM MPPT 8KW 48V
|
SuninvM MPPT 10KW 48V
|
|||
|
Rated Capacity(Watts)
|
|
5000
|
6000
|
8000
|
10,000
|
|||
|
PV
Input
|
MPPT Voltage Range
|
60-115V
|
|
|
|
|||
|
|
Open Circuit Voltage
|
145V
|
|
|
|
|||
|
Grid Input
|
Input Voltage(VAC)
|
110V/220V±15%
|
|
|
|
|||
|
|
Frequency(Hz)
|
50/60Hz
|
|
|
|
|||
|
|
Rated charge current
|
30A
|
|
|
|
|||
|
Output
|
Output Voltage(VAC)
|
110V/220V±15%
|
|
|
|
|||
|
|
Waveform
|
Pure Sine Wave
|
|
|
|
|||
|
|
Phase Type
|
Single Phase
|
|
|
|
|||
|
|
Power Factor
|
1.0
|
|
|
|
|||
|
Others
|
Efficiency
|
≥ 90%
|
|
|
|
|||
|
|
Working Temperature
|
-30 ℃ to +55 ℃
|
|
|
|
|||
|
|
Display
|
LCD
|
|
|
|
|||
|
|
Protection Level
|
IP20
|
|
|
|
|||
Engineering Cases
Packing & Delivery
Certifications
About MULTIFIT
MULTIFIT
was founded in 2009, based on providing the world-class small-scale photovoltaic power plants for civilian solutions and innovative research and development of renewable energy electrical products, we have cultivated a group of sales and R&D teams with ideals, experience and technology. The product has obtained more than 10 patent certificates, which has been exported to Europe, America, Africa, and Latin America etc, more than 50 countries and regions in the world.
Come with MULTIFIT, to power a better world !
Exbihition Shows
FAQ
Q1: Are you a factory or trading company?
A: We are a factory. Multifit Solar is an original design manufacturer of power inverter, MPPT solar charge controller and solar energy system since 2009.
Q2: Where is your factory located? How can I visit there?
A: Headquarter is located in BeiJing, f actories are located in Shantou and Shenzhen City, Guangdong, China.
A: We can provide you samples for quality checking.
A: We usually ship by DHL, UPS, FedEx or TNT. Airline and sea shipping also optional.
Q5: How long is your factory delivery time?
A: 3-7 days for sample order, 5-10 days for MOQ order,15-30 days for 20ft container.
Q6: Is it OK to print my logo on the product?
A: Yes. OEM and ODM are acceptable. There are 20+ technicians in R&D Technology Team and with 3-5 years experience in solar industry.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 2-5 years warranty to our products.
A: We are a factory. Multifit Solar is an original design manufacturer of power inverter, MPPT solar charge controller and solar energy system since 2009.
Q2: Where is your factory located? How can I visit there?
A: Headquarter is located in BeiJing, f actories are located in Shantou and Shenzhen City, Guangdong, China.
Its takes half hours from Airport or Train Station.
Welcome to visit our technology development and production lines at your free time!
Q3: How can I get some samples?
Q3: How can I get some samples?
A: We can provide you samples for quality checking.
Kindly contact us for getting more discount and profitable project solutions.
Q4: How do you ship the goods and how long does it take to arrive?
Q4: How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. Airline and sea shipping also optional.
Q5: How long is your factory delivery time?
A: 3-7 days for sample order, 5-10 days for MOQ order,15-30 days for 20ft container.
Q6: Is it OK to print my logo on the product?
A: Yes. OEM and ODM are acceptable. There are 20+ technicians in R&D Technology Team and with 3-5 years experience in solar industry.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 2-5 years warranty to our products.
Q8: How to contact with Multifit Solar?
A:
You can contact Ms. Christina Lee by sales@multifitsolar.com and phone no. +86-134 3387 9173.
