1. The casting structure is stable, reasonable and beautiful. The cast iron of our company is cast with HD250 grade, which has time aging and annealing aging to ensure that the cast iron body is stable and not deformed and durable.
2. The main parts of the fuselage are the first and second configuration parts imported from the same industry: for example: the guide rails are precision grade guide rails from Taiwan Shangyin or Yintai or ABBA; the screw rods are Japan's NSK, THK or German Rexroth (Rexroth); the system adopts Taiwan's new generation bus absolute value control system and integrated drive; the servo motor adopts the high inertia of Japan's Panasonic servo motor; the wire adopts Japanese wire and custom wire;
- Product Details
- {{item.text}}
Quick Details
-
Dimension(L*W*H):
-
400*400*400
-
Weight (KG):
-
100
-
Repeatability (X/Y/Z) (mm):
-
±0.02
-
Positioning Accuracy (mm):
-
0.02 mm
-
Spindle Power (kW):
-
1
-
X,Y,Z:
-
120*120*100mm
-
Table dimension:
-
100*100mm
-
Maximum operating speed:
-
128m/min
-
Dimensions:
-
400*400*400mm
-
Maximum machining speed:
-
6m/min
-
Positioning accuracy:
-
±0.005/300mm
-
Spindle Speed (rpm):
-
24000 rpm
-
System configuration:
-
TaiWan SynTech/Japan MITSUBISH
-
Repeatability:
-
±0.02
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Range of Spindle Speed(r.p.m):
-
1 - 24000 r.p.m
-
Brand Name:
-
RuiYi
-
Dimension(L*W*H):
-
400*400*400
-
Weight (KG):
-
100
-
Repeatability (X/Y/Z) (mm):
-
±0.02
-
Positioning Accuracy (mm):
-
0.02 mm
-
Spindle Power (kW):
-
1
-
X,Y,Z:
-
120*120*100mm
-
Table dimension:
-
100*100mm
-
Maximum operating speed:
-
128m/min
-
Dimensions:
-
400*400*400mm
-
Maximum machining speed:
-
6m/min
-
Positioning accuracy:
-
±0.005/300mm
-
Spindle Speed (rpm):
-
24000 rpm
-
System configuration:
-
TaiWan SynTech/Japan MITSUBISH
-
Repeatability:
-
±0.02
Products Description
Applicable industries: ceramics, glasses, fiberboard, mobile phones, molds, hardware (hardware accessories in various industries), glass, auto parts, electronic cigarettes, smart wear, PCD circuit boards, accessories, handicrafts, die-casting parts, jewelry, seal signs,
|
A
|
Technical parameters of machine tool：
|
|
|
|
|
||||
|
1
|
The machine body and all parts are made of nano castings
|
|
|
|
|
||||
|
2
|
Table size
|
|
|
130×130mm
|
|
||||
|
3
|
T-groove (width x quantity x spacing)
|
|
|
/
|
|
||||
|
4
|
The largest load
|
|
|
10KG
|
|
||||
|
5
|
Maximum feed height
|
|
|
240mm
|
|
||||
|
6
|
Distance from spindle face to work
|
|
|
0-170mm
|
|
||||
|
7
|
Triaxial travel X/Y/Z
|
|
|
200/170/170mm
|
|
||||
|
8
|
The spindle diameter
|
|
|
Ǿ62mm
|
|
||||
|
9
|
Spindle speed
|
|
|
30000RPM/60000RPM
|
|
||||
|
10
|
Spindle motor power
|
|
|
2.5KW
|
|
||||
|
11
|
Spindle tool library capacity
|
|
|
8
|
|
||||
|
12
|
Tool change time
|
|
|
5S
|
|
||||
|
13
|
The spindle taper
|
|
|
Ǿ6mm
|
|
||||
|
14
|
/Knife library classes
|
|
|
/
|
|
||||
|
15
|
Fast moving rate X/Y/Z
|
|
|
12/12/12m/Min
|
|
||||
|
16
|
Processing speed
|
|
|
1－6m/Min
|
|
||||
|
17
|
Positioning accuracy
|
|
|
±0.01/300mm
|
|
||||
|
18
|
Repetitive positioning accuracy
|
|
|
±0.01/300mm
|
|
||||
|
19
|
Machined surface accuracy
|
|
|
≤Ra3.2
|
|
||||
|
20
|
The machining accuracy
|
|
|
±0.02mm
|
|
||||
|
21
|
Optional four-axis five-axis
|
|
|
Yes
|
|
||||
|
22
|
Angle of rotation of axis A
|
|
|
±105 degrees
|
|
||||
|
23
|
Fifth axis C axis rotation Angle
|
|
|
360 degrees
|
|
||||
|
24
|
Five-axis linkage mode
|
|
|
5 axis with the move
|
|
||||
|
25
|
Working voltage
|
|
|
220V/60HZ
|
|
||||
|
26
|
Machine size (l * W * H)
|
|
|
400×400×400mm
|
|
||||
|
27
|
The body weight
|
|
|
100KG
|
|
||||
|
B
|
Machine tool configuration details brand parameters：
|
|
|
|
|
||||
|
1
|
The system configuration
|
|
|
Taiwan LNC M3000D
|
|
||||
|
2
|
The spindle
|
|
|
2.5KW high-precision, high-speed, high-quiet oil-cooled spindle
|
|
||||
|
3
|
Ball screw
|
|
|
China grinding grade
|
|
||||
|
4
|
Linear guide
|
|
|
China high precision guide H25
|
|
||||
|
5
|
Servo unit
|
|
|
Easy Servo motor
|
|
||||
|
6
|
Wire rod bearing
|
|
|
Taiwan TPI precision grade bearing
|
|
||||
|
7
|
Switching power supply
|
|
|
Taiwan Ming weft
|
|
||||
|
8
|
Electric switch
|
|
|
China chint
|
|
||||
|
9
|
converter
|
|
|
* Square converter
|
|
||||
