Quick Details
-
Rated Loading Capacity:
-
3 Ton
-
Rated Lifting Moment:
-
20.4kn.m
-
Max. Lifting Height:
-
5.5M
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Acntruck
-
Name:
-
Sprider Crane
-
Lifting Capacity:
-
3T
-
Crane type:
-
Spider Crane Mobile Crane Hydraulic Crane
-
Origin:
-
China Original
-
Max. lifting height:
-
5.5m
-
Product name:
-
Sprider Crane
-
Usage:
-
Outdoor Construction Goods Lifting
-
Type:
-
Sprider Crane
-
Capacity:
-
3 Ton
-
Key words:
-
Mini Hydraulic Sprider Crane
Quick Details
-
Weight (KG):
-
3000
-
Marketing Type:
-
New Product 2022
-
Application:
-
Construction work
-
Rated Loading Capacity:
-
3 Ton
-
Rated Lifting Moment:
-
20.4kn.m
-
Max. Lifting Height:
-
5.5M
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Acntruck
-
Name:
-
Sprider Crane
-
Lifting Capacity:
-
3T
-
Crane type:
-
Spider Crane Mobile Crane Hydraulic Crane
-
Origin:
-
China Original
-
Max. lifting height:
-
5.5m
-
Product name:
-
Sprider Crane
-
Usage:
-
Outdoor Construction Goods Lifting
-
Type:
-
Sprider Crane
-
Capacity:
-
3 Ton
-
Key words:
-
Mini Hydraulic Sprider Crane
PRODUCT SPECIFICATIONS
Crane model ZQS21-4
Max. lifting moment 20.4 kN.m
Max. lifting capacity 1700 kg at 1.2m
Working radius Min. 1.2m, Max. 5.155m
Hook height (Approx.) Max. 5.3m
Wire rope Φ8mm × 45m
Hook speed 10m/min
Raising angle 0~75°
Slewing angle 360° continuous
Outriggers
span 2913×2593 mm
span 2913×2593 mm
Gradeability 36% (20°)
Crawling speed 0~1.5 km/h
