Quick Details
-
Poles:
-
2-24P
-
Pitch:
-
7.5mm
-
Standard:
-
UL, IEC
-
Voltage Rating:
-
300V/450V
-
Current Rating:
-
10A/24A
-
Wire range:
-
22-14AWG/2.5m㎡
-
Withstanding Voltage:
-
AC2000V/Min
-
Ambient temperature:
-
-40 centigrade~+105 centigrade
-
Pin header:
-
Brass, Tin Plated
-
Housing:
-
PBT.UL94V-0
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Xinlaiya
-
Model Number:
-
XY300VB-7.5-2P
-
Poles:
-
2-24P
-
Pitch:
-
7.5mm
-
Standard:
-
UL, IEC
-
Voltage Rating:
-
300V/450V
-
Current Rating:
-
10A/24A
-
Wire range:
-
22-14AWG/2.5m㎡
-
Withstanding Voltage:
-
AC2000V/Min
-
Ambient temperature:
-
-40 centigrade~+105 centigrade
-
Pin header:
-
Brass, Tin Plated
-
Housing:
-
PBT.UL94V-0
Specification
|
Prdouct name
|
Terminal block
|
|
Color
|
green
|
|
Standard
|
UL; IEC
|
|
Poles
|
2-24P
|
|
Pitch
|
7.5mm
|
|
Voltage Rating
|
300V/450V
|
|
Current Rating
|
10A/24A
|
|
Wire Range
|
22-14AWG/2.5m㎡
|
|
Withstanding Voltage
|
AC2000V/Min
|
|
Rated torque
|
0.5N.m(3.5Lb-Ln)
|
|
Ambient Temperature
|
-30 centigrade~+120centigrade
|
|
Strip Length
|
5-6mm
|
|
Housing
|
PBT.UL94V-0
|
|
Spring
|
Stainless Steel
|
|
Pin Header
|
Brass, Tin Plate
|
|
Screws
|
M2.5, steel, A3 Zn plated
|
|
Cage
|
-
|
