Quick Details
-
Material:
-
aluminum alloy
-
Product name:
-
3M210-08 Solenoid Vavle
-
ways:
-
5Port 2Position
-
Certificate:
-
ISO9001 CE ROHS
-
Color:
-
Customized Color
-
Working pressure:
-
0.15-0.9Mpa
-
Medium:
-
Clean air
-
Working Temperature:
-
-5-60
-
Size:
-
M5 1/8'' 1/4'' 1/2'' 3/8''
-
Working medium:
-
Clean Air
-
Coil Type:
-
Din type/flying leads
Quick Details
-
Weight (KG):
-
0.2
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
VPC Pneumatic
-
Material:
-
aluminum alloy
-
Product name:
-
3M210-08 Solenoid Vavle
-
ways:
-
5Port 2Position
-
Certificate:
-
ISO9001 CE ROHS
-
Color:
-
Customized Color
-
Working pressure:
-
0.15-0.9Mpa
-
Medium:
-
Clean air
-
Working Temperature:
-
-5-60
-
Size:
-
M5 1/8'' 1/4'' 1/2'' 3/8''
-
Working medium:
-
Clean Air
-
Coil Type:
-
Din type/flying leads
3M210-08 4M 3 port 2 positions Explosion Proof Double Control Pneumatic Air NAMUR Solenoid Valve
Feature
·
3M series solenoid valve is mainly used in the pneumatic actuators, 3M series have 3/2 type single control and 5/3 type double control, thread size range from M5 to 1/2".
·
According to the ISO288-1, ISO4026 and ISO1302 standards. 3M series namur valves are famous for the superior quality and the stable function.
|
Model
|
3M110-M5
|
3M110-06
|
3V210-06
|
3V210-08
|
3V310-08
|
3V310-10
|
3V410-10
|
3M410-15
|
|||||||
|
|
3M120-M5
|
3M120-06
|
3V220-06
|
3V220-08
|
3V320-08
|
3V320-10
|
3V420-10
|
3M420-15
|
|||||||
|
Working Medium
|
Clean air(40μm Filteration)
|
|
|
|
|
|
|
|
|||||||
|
Acting Type
|
Internal Guide
|
|
|
|
|
|
|
|
|||||||
|
Joint Size
|
Import=M5 Export=M5
|
Import=1/8 Export=1/8
|
Import=1/8 Export=1/8
|
Import=1/4 Export=1/8
|
Import=1/4 Export=1/4
|
Import=3/8 Export=3/8
|
Import=3/8
Export=3/8
|
Import=1/2
Export=1/2
|
|||||||
|
Sectional Area
|
5.5mm
2
(CV=0.31)
|
12mm
2
(CV=0.67)
|
14mm
2
(CV=0.78)
|
16mm
2
(CV=0.89)
|
25mm
2
(CV=1.4)
|
30mm
2
(CV=1.68)
|
30mm
2
(CV=1.68)
|
50mm
2
(CV=2.79)
|
|||||||
|
Working Pressure
|
0.15~0.9Mpa
|
|
|
|
|
|
|
|
|||||||
|
Max.
Pressure
|
1.2Mpa
|
|
|
|
|
|
|
|
|||||||
|
Working
Temperature
|
-5~60℃
|
|
|
|
|
|
|
|
|||||||
|
Voltage Range
|
-15%~10%
|
|
|
|
|
|
|
|
|||||||
|
Heat Resistant Grade
|
B
|
|
|
|
|
|
|
|
|||||||
|
Protective Class
|
IP65(DIN40050)
|
|
|
|
|
|
|
|
|||||||
|
Coil Type
|
Din type、Flying leads
|
|
|
|
|
|
|
|
|||||||
|
Max.Acting Frequency
|
4Times/S
|
|
|
|
|
|
|
|
|||||||
Ordering Code
3M Series Solenoid Valve
3M 2 10 - 08 -
□
AC220V
3M
→Type Code
3M:3Port,2Position
2
→
Series Code
1:100 Series 2:200 Series
3:300 Series 4:400 Series
□
→
Coil Type
Blank:Din type I:Fly leads
Blank:Din type I:Fly leads
10
→Coil
10:Single control
20:Double control
08→Joint Size
M5:M5
06:G1/8"
08:G1/4" 10:G3/8"
15:G1/2"
AC220V→Standard Voltage
DC12V DC24V
AC24V 50/60H
Z
AC110V 50/60H
Z
AC220V 50/60H
Z
AC380V 50/60H
Z
