Quick Details
-
Grade:
-
steel
-
Place of Origin:
-
Jiangsu, China
-
Model Number:
-
5.5-14mm
-
Brand Name:
-
KINGTALE
-
Name:
-
KONE elevator wire KM917848G01 elevator wire rope
-
Structure:
-
1*19/1*7/7*9/7*19
-
Surface treatment:
-
galvanized
-
Tensile Strength:
-
1570mpa,1770mpa,1870mpa,2160mpa
-
HS Code:
-
7312100000
-
Core:
-
fiber core or steel core
-
MOQ::
-
5000m
-
Packing Term:
-
1000m per reel on wooden reel,then packed on wooden pallet
Quick Details
-
Steel Grade:
-
45#;60#;70#
-
Type:
-
galvanized
-
Tolerance:
-
±15%
-
Grade:
-
steel
-
Place of Origin:
-
Jiangsu, China
-
Model Number:
-
5.5-14mm
-
Brand Name:
-
KINGTALE
-
Name:
-
KONE elevator wire KM917848G01 elevator wire rope
-
Structure:
-
1*19/1*7/7*9/7*19
-
Surface treatment:
-
galvanized
-
Tensile Strength:
-
1570mpa,1770mpa,1870mpa,2160mpa
-
HS Code:
-
7312100000
-
Core:
-
fiber core or steel core
-
MOQ::
-
5000m
-
Packing Term:
-
1000m per reel on wooden reel,then packed on wooden pallet
KONE elevator wire KM917848G01 elevator wire rope, elevator steel wire rope
1) Product: KONE elevator wire KM917848G01 elevator wire rope, elevator steel wire rope
2) Construction: 1*7/1*19/7*7/7*19
3) Diameter Range: 1.5mm-10mm
4) Standard: GB, ISO, DIN, ASTM
5) Packing: Plastic Reel or Wooden Reel
Outer packing: Plywood pallets
6) Application: Perfectly suitable for use around sheaves and pulleys, conveyor belts, security cables, gym equipment, garage and industrial door cables, general engineering applications, caternary wire, mast stays, signage & display. Makes perfect winch cable.
| Structure | 7X7/7*19/1*7/1*19 |
| Diameter | As your requirements |
| Materials | 45#,60#,70# carbon steel |
| Surface | Hot dipper galvanized, electric galvanized, ungalvanized |
| Lay | Right hand regular lay or left hand regular lay |
| Standards | ASTM ,DIN,GB,BS |
| Tensile strength | 1570MPa, 1670MPa, 1770MPa ,1870MPa ,1960MPa |
| Application | Excavator ,Highway guardrail cable, barrier, communication, telecommunications, overhead conductors, guy grip etc |
| Packing | Coil, plastic reel, wooden reel |
Technical Specification
|
Diameter |
Approx. Weight |
DIN3060 |
|
|
Min.Breaking Load |
|||
|
mm |
kg/100m |
1570N/mm 2 |
1770N/mm 2 |
|
1.5 |
0.92 |
1.26 |
1.43 |
|
1.8 |
1.32 |
1.82 |
2.05 |
|
2.0 |
1.63 |
2.27 |
2.56 |
|
2.2 |
1.98 |
2.72 |
3.06 |
|
2.5 |
2.55 |
3.55 |
4.00 |
|
3.0 |
3.68 |
5.12 |
5.29 |
|
4.0 |
6.53 |
9.09 |
9.40 |
|
5.0 |
10.21 |
14.21 |
21.20 |
|
6.0 |
14.70 |
20.50 |
28.20 |
|
8.0 |
26.14 |
33.30 |
37.60 |
|
10.0 |
40.84 |
52.10 |
58.80 |
|
|
|||
