Quick Details
-
Power:
-
hydraulic
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
ENWEI
-
Maximum Digging Height:
-
7340 mm
-
Maximum Digging Depth:
-
4500 mm
-
Machine Weight:
-
13000 kg
-
Max Digging Radius:
-
7500 mm
-
Rated Speed:
-
13-14 r/min
-
Transmission:
-
Hydraulic Transmission
-
Drive Type:
-
Internal Combustion Drive
-
capacity of hydraulic oil tank (L):
-
180
-
capacity of fuel tank (L):
-
220
-
wheelbase (mm):
-
2620
-
Max. running speed (km/h):
-
28
Quick Details
-
Operating Weight:
-
10 TON
-
Bucket capacity:
-
0.6 m3
-
Engine Brand:
-
Cummins
-
Power:
-
hydraulic
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
ENWEI
-
Maximum Digging Height:
-
7340 mm
-
Maximum Digging Depth:
-
4500 mm
-
Machine Weight:
-
13000 kg
-
Max Digging Radius:
-
7500 mm
-
Rated Speed:
-
13-14 r/min
-
Transmission:
-
Hydraulic Transmission
-
Drive Type:
-
Internal Combustion Drive
-
capacity of hydraulic oil tank (L):
-
180
-
capacity of fuel tank (L):
-
220
-
wheelbase (mm):
-
2620
-
Max. running speed (km/h):
-
28
Products Description
HT135W is new generation full hydraulic wheel excavator designed and produced by Jining ENWEI Intelligent Technology Co., Ltd. It adopts Cummins engine with high power and low fuel consumption, which guarantees the strong power and power reserve; the accurate matching of high efficiency system and bridge-case ensures random switch of working state and running state; equipped with imported hydraulic components, hydraulic system and engine, provide accurate flow, improve operation efficiency. The hydraulic system has the characteristics of high reliability, high performance-price ratio, safety, green, comfort and convenient operation, in the meantime, we can provide a variety of optional special configuration, which can meet the requirement of different countries and customers.
Product Paramenters
|
HT135W Wheeled Excavator
|
|
|
|
Shipping Length（mm）
|
7350
|
|
|
Shipping Height（mm）
|
3005
|
|
|
Overall Width（mm）
|
2520
|
|
|
Tail Swing Radius（mm）
|
2390
|
|
|
Wheelbase（mm）
|
2600
|
|
|
Wheel Tread（mm）
|
2000
|
|
|
Tyre Type
|
9.00-20
|
|
|
Max dig Height（mm）
|
7637
|
|
|
Max dump Height（mm）
|
6240
|
|
|
Max dig Depth（mm）
|
4347
|
|
|
Max dig Radius（mm）
|
7654
|
|
|
Engine
|
Cummins 92KW/2000rpm
|
|
|
Hydraulic System pressure
|
28Mpa
|
|
|
Hydraulic System flow
|
130*2L/min
|
|
|
Bucket Volume（m3）
|
0.53
|
|
|
Bucket digging force（KN）
|
85
|
|
|
Arm digging force（KN）
|
53
|
|
|
Rotation Speed（r/min）
|
13-14
|
|
|
Travel Speed（km/h）
|
28
|
|
|
Approximate Weight（kg）
|
13500
|
|
Advantage:
Comfort: Spacious and comfortable cab, providing excellent all-round vision.
New type suspension seat conforms ergonomics, improve driver's operation comfort.
Intelligence: Adopt smart driving computer, with big data analysis and storage function, timely warning prompt.
Configuration: National II standard Cummins engine, adopts new technology of low fuel consumption and strong power, accurate
matching of original imported main hydraulic system and engine, provide accurate flow, improve operation efficiency.
Kinetic energy: All the time four wheels drive, with high and low speed gears, high speed running and quick transfer.
High drive power, agile escape ability, strong cross-country power.
Comfort: Spacious and comfortable cab, providing excellent all-round vision.
New type suspension seat conforms ergonomics, improve driver's operation comfort.
Intelligence: Adopt smart driving computer, with big data analysis and storage function, timely warning prompt.
Configuration: National II standard Cummins engine, adopts new technology of low fuel consumption and strong power, accurate
matching of original imported main hydraulic system and engine, provide accurate flow, improve operation efficiency.
Kinetic energy: All the time four wheels drive, with high and low speed gears, high speed running and quick transfer.
High drive power, agile escape ability, strong cross-country power.
