Quick Details
-
Color:
-
Can be customized
-
Panel Size:
-
512*1024 mm, 512*1024 mm
-
Place of Origin:
-
shenzhen
-
Model Number:
-
street light pole LED Double-sided display screen
-
Brightness:
-
≥5500cd/㎡, ≥5500cd/㎡
-
pixel density:
-
P4, P4
-
Resolution:
-
128 (width)*256 (height)*2=32768 pixels *2
-
Product name:
-
street light pole LED Double-sided display screen
-
Pixel pitch:
-
P4
-
Display size:
-
512(W) x 1024mm(H)
-
Display resolution:
-
128 points (width)*256 points (height)*2=32768 pixels *2
-
Frame size:
-
582mm (W) *1124mm (H) *160mm (H)
-
Case color:
-
Gray, white, black
-
Visual distance:
-
4m~200m
-
Maximum brightness:
-
≥5500cd/㎡
-
Ambient temperature requirements:
-
-25℃~+70℃,10%~98%RH
-
Box weight:
-
about 40KG
Quick Details
-
Application:
-
Outdoor
-
Type:
-
LED
-
Brand Name:
-
teejion
-
Color:
-
Can be customized
-
Panel Size:
-
512*1024 mm, 512*1024 mm
-
Place of Origin:
-
shenzhen
-
Model Number:
-
street light pole LED Double-sided display screen
-
Brightness:
-
≥5500cd/㎡, ≥5500cd/㎡
-
pixel density:
-
P4, P4
-
Resolution:
-
128 (width)*256 (height)*2=32768 pixels *2
-
Product name:
-
street light pole LED Double-sided display screen
-
Pixel pitch:
-
P4
-
Display size:
-
512(W) x 1024mm(H)
-
Display resolution:
-
128 points (width)*256 points (height)*2=32768 pixels *2
-
Frame size:
-
582mm (W) *1124mm (H) *160mm (H)
-
Case color:
-
Gray, white, black
-
Visual distance:
-
4m~200m
-
Maximum brightness:
-
≥5500cd/㎡
-
Ambient temperature requirements:
-
-25℃~+70℃,10%~98%RH
-
Box weight:
-
about 40KG
|
|
P1.25
|
P1.579
|
P1.667
|
P1.875
|
P2
|
P2.5
|
P3
|
P4
|
|||||||
|
Lamp bead packaging specification
|
SMD1010
|
SMD1212
|
SMD1212
|
SMD1515
|
SMD1515
|
SMD1515
|
SMD2020
|
SMD2020
|
|||||||
|
Pixel density(dots/m2)
|
640000
|
401111
|
360000
|
284444
|
250000
|
160000
|
111111
|
62500
|
|||||||
|
Module size (mm)
|
240x120x8.6(LxHxT)
|
|
|
|
|
|
|
|
|||||||
|
Module Resolution
|
192x96
|
152x76
|
144x72
|
128x64
|
120x60
|
96x48
|
80x40
|
60x30
|
|||||||
|
Refresh rate (Hz)
|
3840
|
|
|
|
|
|
|
|
|||||||
|
Frame frequency(Hz)
|
60hz
|
|
|
|
|
|
|
|
|||||||
|
Gray level (bit)
|
14-18bit
|
|
|
|
|
|
|
|
|||||||
|
Signal interfacemode
|
HUB75
|
|
|
|
|
|
|
|
|||||||
|
Module bottomshell material
|
Silicone soft bottom shell
|
|
|
|
|
|
|
|
|||||||
|
Module weight(KG/Piece)
|
0.215
|
0.203
|
0.195
|
0.216
|
0.205
|
0.175
|
0.175
|
0.17
|
|||||||
|
Degree of protection
|
IP30
|
|
|
|
|
|
|
|
|||||||
|
Installation/mainte nance mode
|
Front and rear installation/maintenance
|
|
|
|
|
|
|
|
|||||||
|
Brightness (cd)
|
≥600
|
≥650
|
≥650
|
≥750
|
≥750
|
≥750
|
≥750
|
≥750
|
|||||||
|
Color temperature (K)
|
≤12000adjustable
|
|
|
|
|
|
|
|
|||||||
|
coordinate
|
X:0.2500 Y:0.3000
|
|
|
|
|
|
|
|
|||||||
|
Brightness uniformity
|
≥95%
|
|
|
|
|
|
|
|
|||||||
|
Horizontal/verticalviewing angle
|
≥170°/ ≥160°
|
≥160°/ ≥140°
|
|
|
|
|
|
|
|||||||
|
contrast ratio
|
≥5000:1
|
|
|
|
|
|
|
|
|||||||
