Design Features
Centrifugal Fan
Well-Know brand centrifugal fans, with galvanized steel and which is statically and dynamically balanced.
Condensate Drain Pan
L shaped drain pan, suitable for horizontal and/or vertical installation.
High Efficiency Coil
Coil are made of copper tubes and high exchange surface area aluminum blue fins. All coils are 100% tested against leaks by 30bar
(3Mpa) air pressure, with 3/4” pipe connections and air bleed vent.
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
OUTES
-
Dimension(L*W*H):
-
1995*250*520MM
-
Warranty of core components:
-
2 Years
-
Weight (KG):
-
44 KG
-
Showroom Location:
-
None
-
After-sales Service Provided:
-
Free spare parts
-
Marketing Type:
-
New Product 2020
Quick Details
-
Type:
-
Fan Coil Unit
-
Mounting:
-
Ceiling Mount
-
Airflow:
-
1360m³/h
-
Place of Origin:
-
China
-
Brand Name:
-
OUTES
-
Dimension(L*W*H):
-
1995*250*520MM
-
Warranty of core components:
-
2 Years
-
Weight (KG):
-
44 KG
-
Showroom Location:
-
None
-
After-sales Service Provided:
-
Free spare parts
-
Marketing Type:
-
New Product 2020
Video Description
Product Family
Product Overview
Product Specification
Details Images
细节图一
细节图二
细节图三
|
Model
|
|
|
/
|
OFP-102ML
|
OFP-136ML
|
OFP-170ML
|
OFP-204ML
|
||
|
CFM
|
|
|
|
600
|
800
|
1000
|
1200
|
||
|
Power Supply
|
|
|
/
|
220-240V/1N/50Hz
|
220-240V/1N/50Hz
|
220-240V/1N/50Hz
|
220-240V/1N/50Hz
|
||
|
Air Flow Rate
|
|
H
|
m3/h
|
1020
|
1360
|
1700
|
2040
|
||
|
|
|
M
|
m3/h
|
850
|
1020
|
1360
|
1700
|
||
|
|
|
L
|
m3/h
|
650
|
850
|
1100
|
1360
|
||
|
Heating
|
2Pipe Heating Capacity
|
H
|
KW
|
8.0
|
10.8
|
13.5
|
15.0
|
||
|
|
|
M
|
KW
|
7.0
|
8.0
|
11.0
|
13.5
|
||
|
|
|
L
|
KW
|
5.5
|
7.0
|
8.9
|
11.0
|
||
|
|
4Pipe Heating Capacity
|
H
|
KW
|
4.3
|
5.8
|
7.4
|
8.8
|
||
|
|
|
M
|
KW
|
3.6
|
4.4
|
5.9
|
7.4
|
||
|
|
|
L
|
KW
|
2.7
|
3.6
|
4.8
|
5.9
|
||
|
|
Water Flow Rate
|
|
L/h
|
370
|
500
|
640
|
760
|
||
|
|
Water Pressure Drop
|
|
kPa
|
17
|
21
|
30
|
35
|
||
|
Power Input
|
|
|
W
|
105
|
156
|
183
|
190
|
||
|
Sound Pressure
|
|
|
dB(A)
|
45
|
46
|
50
|
52
|
||
|
Fan
|
|
Type
|
|
Centrifugal Fan
|
Centrifugal Fan
|
Centrifugal Fan
|
Centrifugal Fan
|
||
|
|
|
Model
|
|
SYP130/190J
|
SYP130/190J
|
SYP130/190J
|
SYP130/190J
|
||
|
|
|
Quantity
|
|
3
|
3
|
4
|
4
|
||
|
Motor
|
|
Type
|
|
3-speed Motor
|
3-speed Motor
|
3-speed Motor
|
3-speed Motor
|
||
|
|
|
Quantity
|
|
2
|
2
|
2
|
2
|
||
|
Connection
|
Water Inlet/Outlet Pipe
|
|
Inch
|
ZG3/4"
|
ZG3/4"
|
ZG3/4"
|
ZG3/4"
|
||
|
|
Condensate Discharge
|
|
Inch
|
26
|
26
|
26
|
26
|
||
|
Electrical Shock Proof
|
|
|
/
|
Class I
|
Class I
|
Class I
|
Class I
|
||
|
Water Proof Class
|
|
|
/
|
IPX0
|
IPX0
|
IPX0
|
IPX0
|
||
|
Net Weight(With Feet)
|
|
2/4 Pipe
|
kg
|
38/40
|
38/40
|
44/48
|
44/48
|
||
|
Net Weight(No Feet)
|
|
2/4 Pipe
|
kg
|
36/38
|
36/38
|
42/46
|
42/46
|
||
|
Net Dimensions ( With FeetL*W*H)
|
|
|
mm
|
1605x205x581
|
1605x205x581
|
1905x205x581
|
1905x205x581
|
||
|
Net Dimensions (No Feet L*W*H)
|
|
|
mm
|
1605x205x481
|
1605x205x481
|
1905x205x481
|
1905x205x481
|
||
|
Packing Dimensions ( With FeetL*W*H)
|
|
|
mm
|
1695*250*520
|
1695*250*520
|
1995*250*520
|
1995*250*520
|
||
|
Packing Dimensions ( L*W*H)
|
|
|
mm
|
1695*250*520
|
1695*250*520
|
1995*250*520
|
1995*250*520
|
||
Application
Recommend Products
About OUTES
OUTES was established in 2 0 0 6 with an industry park of 500,000
m
2
, specializing in sales, R&D and manufacturing air conditioner, Cooling & Heating heat pump, Hot Water heat pump, Swimming Pool heat pump, Commercial heat pump, Fan Coils, Air Ventilation Unit, Water Purification Equipment and Pressure Water Tank.
OUTES has reputation in domestic market. With 2000 distributors, 1000 After-sales Service Center and 10 local warehouse.
