Quick Details
-
Dimension(L*W*H):
-
Depends
-
Weight:
-
500kg
-
Certification:
-
ISO9001
-
color:
-
blue
Quick Details
-
Place of Origin:
-
Shandong, China
-
Model Number:
-
CLHS
-
Brand Name:
-
XINGFU
-
Dimension(L*W*H):
-
Depends
-
Weight:
-
500kg
-
Certification:
-
ISO9001
-
color:
-
blue
- 1. Integration design, make the boiler easier in installation.
- 2. Take use of the European technology, the combustion efficiency increase 30-50%. With the design of return flow mode, the higher temperature flow will stay long time inside the furnace. The heat can be absorbed sufficiently.
- 3. With double stage feeding system, avoid any back fire problem and reduce the load of feeding system.
- 4. Intelligent control system make the boiler easier in operation, but with higher automation.
Technical Information
|
Model |
|
CLHS0.041 |
CLHS-0.058 |
CLHS-0.088 |
CLHS-0.12 |
|
Working pressure |
Mpa |
Atmospheric pressure |
|||
|
Efficiency |
% |
93% |
|||
|
Thermal power |
Kcal |
35,000 |
50,000 |
75,000 |
100,000 |
|
Heating area |
m2 |
350 |
500 |
750 |
1000 |
|
Voltage |
V |
220 |
220 |
220 |
220 |
|
ID fan power |
Kw |
0.12 |
0.12 |
0.18 |
0.25 |
|
Blast fan power |
Kw |
0.085 |
0.12 |
0.12 |
0.24 |
|
Chimney diameter |
MM |
114 |
140 |
165 |
165 |
|
Hot water output |
Kg/hr |
875 |
1250 |
1875 |
2500 |
|
Water inlet and outlet diameter |
MM |
39 |
51 |
51 |
51 |
|
Dust collector mode |
|
Wet scrubber dust collector |
|||
|
Fuel consumption |
Kg/hr |
6.67 |
9.52 |
14.3 |
19 |
|
Size (LxWxH) |
MM |
1350x570 x1270 |
1400x600 x1350 |
1638x700 x1360 |
1840x750 x1470 |
|
Weight |
Kg |
350 |
420 |
520 |
580 |
