Quick Details
-
Brand Name:
-
Huaxu
-
Model Number:
-
LF280K
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
5.5KG, 5250±50g
-
The charging ratio:
-
1C
-
The discharge rate:
-
1C
-
Electric Energy:
-
51.2 Wh
-
Nominal Voltage:
-
3.2V
-
Capacity:
-
105Ah/160Ah/ 280Ah
-
Certification:
-
MSDS,CE,ROHS,UN 38.3
-
Max Charge Voltage:
-
3.29V
-
Max Discharge Current:
-
100A/120A/150A/280A
-
Long Cycle life:
-
3500~10000 Times
-
Keywords:
-
Rechargeble lifepo4 Battery
-
Dimension:
-
H118.5*W160*T49.9
-
Warranty:
-
5years
Quick Details
-
Storage Type:
-
/
-
Anode Material:
-
LFP
-
Application:
-
Home Appliances, Golf Carts, Electric Bicycles/Scooters, electric vehicles, Electric Power Systems, Solar Energy Storage Systems, Electric Forklifts
-
Brand Name:
-
Huaxu
-
Model Number:
-
LF280K
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
5.5KG, 5250±50g
-
The charging ratio:
-
1C
-
The discharge rate:
-
1C
-
Electric Energy:
-
51.2 Wh
-
Nominal Voltage:
-
3.2V
-
Capacity:
-
105Ah/160Ah/ 280Ah
-
Certification:
-
MSDS,CE,ROHS,UN 38.3
-
Max Charge Voltage:
-
3.29V
-
Max Discharge Current:
-
100A/120A/150A/280A
-
Long Cycle life:
-
3500~10000 Times
-
Keywords:
-
Rechargeble lifepo4 Battery
-
Dimension:
-
H118.5*W160*T49.9
-
Warranty:
-
5years
PRODUCT SPECIFICATIONS
|
Battery Type
|
Lithium Ion LiFePO4
|
|
|
|
Model Name
|
CALB CATL EV LiShen Higee LF100/ LF120/ LF150/ LF280
|
|
|
|
Housing Material
|
LifePo4
|
|
|
|
Typical Voltage
|
3.29V
|
|
|
|
Typical Capacity
|
100Ah/ 150Ah/ 120Ah/ 280Ah
|
|
|
|
Internal resistance
|
0.2~0.5mΩ
|
|
|
|
Manufacture
|
Huaxu
|
|
|
|
Standard charge and discharge Cut-off Voltage
|
3.65V/2.5V
|
|
|
|
Charging Working Temperature
|
0°C ~ 45°C
|
|
|
|
Max Pulse Charge/Discharge Current（30s）
|
1C 280A/ 1C 280A
|
|
|
|
Cycle life
|
6000 times (80% DOD)
|
|
|
|
Applications/ Used for
|
Engine starting battery, electric bicycle/motorcycle/scooter, golf trolley/carts, power tools...Solar and wind power system, RV,
caravan etc... |
|
|
|
Note
|
1.All of the LiFePo4 Lithium Battery of the QR code is intact, Grade A, Brand new.
2.The price come with Bus bars and Bolts, one battery will come with one set bus bar and bolt（e.g.,If buy 4pcs battery, we will send
4pcs cells with 4 pcs busbars and 8pcs bolts）If need more please contact us online. Thank you! 3.The busbars size:86*15*2mm(cooper plated with nickel) Screw size:M6. 4.We will test all the battery Voltage ,Internal resistance and capacity before delivery. |
|
|
1.All popular products are in stock!
The hottest EV 280Ah and EV 304Ah are in the French warehouse, can be shipped within 2~5days.(DDP Accepted)
2.The price comes with Bus bars and Bolts,one battery will come with one set bus bar and bolt(e.g.,If buy 2pcs battery,we will send 2pcs cells with 2 pcs busbars and 4pcs bolts)If need more please contact us online.Thank you!
3.The busbars size:90*20*2mm(cooper plated with nickel) Screw size:M6
4.We will test all the battery Voltage ,Internal resistance and capacity before delivery
5.EV, CATL, LISHEN, CALB, REPT, Yinglong batteries. Fresh Stock for them ready to ship. Please feel free to contact us if any need to them.
3.The busbars size:90*20*2mm(cooper plated with nickel) Screw size:M6
4.We will test all the battery Voltage ,Internal resistance and capacity before delivery
5.EV, CATL, LISHEN, CALB, REPT, Yinglong batteries. Fresh Stock for them ready to ship. Please feel free to contact us if any need to them.
6.OEM and ODM designs and lables are welcome.
Attention:
During the use of the battery, the following regulations must be observed:
1) Do not remove the battery from its original packaging before use.
2) Do not put the batteries together sporadically to avoid accidental short circuit.
3) Do not heat the battery above 100 ° C or burn it.
4) Do not charge the primary lithium battery.
5) Do not weld directly on the surface of the battery. Use a battery with pre installed solder legs or leads.
6) Do not mix new and used batteries, or batteries from different sources.
7) It is strictly prohibited to short circuit between positive and negative and reverse connection between positive and negative electrodes.
8) Do not disassemble or dissect the battery.
Reminder:
*Before using the battery, please fully evaluate and operate in strict accordance with the Product Specification.
*Misuse may cause heating or even explosion of the battery, which may cause personal injury or property loss.
*Our company will not bear any responsibility for any accident caused by misuse of the product due to failure to operate as required.
*In case of any problem, please contact our customer service personnel in time.
