5 Axis CNC Stone Carving Machine With Vertical Rotary To Make 3D Sculptures Statues
5 Axis CNC Stone Carving Machine With Vertical Rotary To Make 3D Sculptures Statues
5 Axis CNC Stone Carving Machine With Vertical Rotary To Make 3D Sculptures Statues
5 Axis CNC Stone Carving Machine With Vertical Rotary To Make 3D Sculptures Statues
5 Axis CNC Stone Carving Machine With Vertical Rotary To Make 3D Sculptures Statues
5 Axis CNC Stone Carving Machine With Vertical Rotary To Make 3D Sculptures Statues
5 Axis CNC Stone Carving Machine With Vertical Rotary To Make 3D Sculptures Statues
5 Axis CNC Stone Carving Machine With Vertical Rotary To Make 3D Sculptures Statues

5 Axis CNC Stone Carving Machine With Vertical Rotary To Make 3D Sculptures Statues

FOB Reference Price: Get Latest Price
≥1 Sets
US $1111111
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Production Capacity:
24 hours
Place of Origin:
Shandong, China
Brand Name:
CHAODA
Voltage:
3 PHASE, 380V
Dimension(L*W*H):
4.1m * 3.3m * 4m
Weight:
9000 kg
Marketing Type:
Hot Product
model:
5 Axis CNC Stone Carving Machine With Vertical Rotary
lathe bed structure:
heavy duty steel structure
rotary working size:
1500mm diameter, 2000mm length
spindle power:
12kw water cooling
driving system:
Japan Servo motor and driver
control system:
5 axis Syntec
Auto oil system:
yes
option 1:
double rotary
option 2:
4 axis rotary
option 3:
3d scanner

Quick Details

Type:
CNC Router
Power:
12KW
Cutting thickness (max):
1500mm
Production Capacity:
24 hours
Place of Origin:
Shandong, China
Brand Name:
CHAODA
Voltage:
3 PHASE, 380V
Dimension(L*W*H):
4.1m * 3.3m * 4m
Weight:
9000 kg
Marketing Type:
Hot Product
model:
5 Axis CNC Stone Carving Machine With Vertical Rotary
lathe bed structure:
heavy duty steel structure
rotary working size:
1500mm diameter, 2000mm length
spindle power:
12kw water cooling
driving system:
Japan Servo motor and driver
control system:
5 axis Syntec
Auto oil system:
yes
option 1:
double rotary
option 2:
4 axis rotary
option 3:
3d scanner

5 Axis CNC Stone Carving Machine With Vertical Rotary To Make 3D Sculptures Statues

  • Heavy duty steel structure, keep machine with very good stability.
  • Adopt top quality machine parts,to make machine with high performance and durability.
  • Machine is with a big 5 axis rotary device, can process different kinds of 3d stone statues sculptures roman columns corbel pilasters cylinders pillars...
  • With saw blade function,for fast rough machining,10 times saved working time.
  • Advanced Syntec control system,very stable and convenient to use.

Model No.

JCS1520R 5AXIS

Lathe bed

heavy duty steel structure

Table

No

Rotary Working size

1500mm diameter, 2000mm length

Spindle power

12kw water cooling spindle

Spindle rotating

12000rpm

Max.travelling speed

55m/min

Max.working speed

15m/min

Control system

5 Axis Syntec

Motor

Servo

Saw blade function

yes

Auto oil system

yes

Voltage

AC380v,3 phase,50Hz

It can work on many materials like Marble, Granite, Artificial Stone, Terrazzo, Limestone, Sandstone,

Travertine, Quartzite, Slate, Grindstone ,Jade, Crystal, Glass, Acrylic, Wood, PVC, EPS Foam, Aluminum composite panel, Aluminum block, Copper and so on.

1. Sample testing before shipment
2. Provide 2 days free training for each machine
3. 12 months warranty for each machine
4. Friendly English version manual and operation videos for studying
5. Free technical support by phone,email,chatting or remote
6. Engineers available to service machinery overseas
