ASME ADR CCS ISO LPG Transportation Tank Container 20Feet T50 Skeleton Potable Container Whastapp +8615897603919

ASME ADR CCS ISO LPG Transportation Tank Container 20Feet T50 Skeleton Potable Container Whastapp +8615897603919

FOB Reference Price: Get Latest Price

≥1 Pieces

US $12500

≥2 Pieces

US $8900

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Internal Dimensions(l x W x H)(mm):: 2390*18*5791

Place of Origin:: Hubei, China

Brand Name:: China Local Brand

Capacity of Tank body:: 24000Liters

Keywords:: LPG Potable Container

20FT LPG Potable Container:: ASME Standard

LPG Gas Container:: China Classification Society

Potable Container:: ASME Standard CCS Certified ADR

Tank Container:: LO2 LN2 LAR LN2O Ethylene LPG

LPG Tank Container:: 20FT 30FT 40FT

Whastapp:: +86 15897603919

Quick Details

Type:: Tank Container

Capacity:: 24000

External Dimensions(l x W x H)(mm):: 6058*2438*2438

Internal Dimensions(l x W x H)(mm):: 2390*18*5791

Place of Origin:: Hubei, China

Brand Name:: China Local Brand

Capacity of Tank body:: 24000Liters

Keywords:: LPG Potable Container

20FT LPG Potable Container:: ASME Standard

LPG Gas Container:: China Classification Society

Potable Container:: ASME Standard CCS Certified ADR

Tank Container:: LO2 LN2 LAR LN2O Ethylene LPG

LPG Tank Container:: 20FT 30FT 40FT

Whastapp:: +86 15897603919

Product Description

ASME Standard 20FT ISO Tank Container LPG Potable Container For Sales Whastapp +8615897603919

1. Potable Tank Container: 20FT 30FT 40FT

2. With all accessories : DN50 Safety relief valve, sund shield gas phase foot valve, liquid phase foot valve, temperature gauge , pressure meter, manhole

3. Potable tank Container Filling Medium: Acetone,Butanol,Ethanol,Gasoline,Toluene,Sodium hydroxide solution,Monomer styrene,Ammonia,Benzene,Butyl acetate,Carbon disulfide Dimethylamine water,Ethyl acetate,Isobutanol,Isopropanol,Kerosene,Methanol,Crude oil,Xylene Acetone cyanide,Glacial acetic acid,Acetic acid solutioon,Anhydrous chloraldehye,Formaldehyde solution Phosphorus trichloride,Hydrated sulfide sodium,Aqueous hydrogen peroxide,Nitric acid,Amine water

4. Potable tank material: Q345R, Stainless steel

ASME Standard 20FT ISO Tank Container

LPG Tank capacity: 24000Liters

20FT 30FT 40FT For choice

CCS Certificate

Factory directly sales

Good price

Specification

Tanker body	Item	data
Main parameter	Filling medium	LPG
		capacity	24000Liters
		Material of tank body	Q345R
		Thickness of body	18mm
		Thickness of head	18mm
		Kerb weight of tank body	8800kgs
		Loading weight	23280kgs
		Outside dimension(inner diameterthicknesslength )	2390185791mm
		Design pressure	1.71Mpa
		Corrosion allowance	1mm
		Filling ratio	0.95
Testing	Hot treatment type	Stress relieved hot treatment
		Hot treatment temperature	620±20℃
		nondestructive testing method	100% X-ray inspection
		Hydraulic test pressure	2.14Mpa
		Service year	20
		LPG gas density	420(50℃)
Safety device	Level gauga, safe valve, pressure meter, temperature meter, Backflow valve, relief valve , Liquid foot valve,

Details Images

24000Liters Potable LPG Gas Container

Optional different type skeletal

LPG Gas Container

Customized by customers, Color , LOGO

gas phase foot valve, liquid phase foot valve

Temperature and pressure meter

20FT

The drawing of ISO LPG Tank Container

Package and shipment

20Feet or 40HQ shipment for LPG Skid.

Characteristic of LPG Storage Tank

The Characteristic of LPG TANK from our Company:

1. The tank is one important part of the liquefied gas semi-trailer.

2. The tank consists of the cylinder shell and standard ellipsoidal head.

3. The tank’s material is high intension steel plate Q345R that is specially used in pressure vessel.
4. The double side auto-welding is adopted in tank’s main welding joints.

5. The 100% x-ray checking shall be done to A and B kinds welding joints and shall accord with Ⅱ grade requirements of JB4730 Non-destruction testing for Pressure vessels’.

6. The fully magnetism checking or penetrate checking shall be done to C and D kinds welding joints and shall accord with Ⅰ grade requirements of JB4730. PWHT shall be done after the welding of tank. The hydraulic test shall be done after the post weld heat treatment.

7. The manhole of the tank is used for cleaning and maintenance of the tank’s inside. The baffles are mounted on the tank’s inside to prevent wave. The seat is welded on the tank’s bottom.

8.After tanker assembly, have carried on the gas leak test to the complete vehicle according to the design pressure, authorize third party to have qualification supervise after examining by country qualified making available to the users.
