Quick Details
-
Model Number:
-
CKF30-20NO
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
AkuSense
-
Theory:
-
Optical sensor
-
Output:
-
NPN
-
Sensing distance:
-
2~20mm Adjust
-
Size:
-
M30
-
Material:
-
PBT
-
Operating Voltage:
-
10~30V DC(Ripple<10%)
-
Output Type:
-
NPN Open collector, NO
-
Switch frequency:
-
100Hz
-
Material active face:
-
PBT
-
Operating Temp:
-
-25℃~+70℃
-
Protection Degree:
-
IP67
Quick Details
-
Use:
-
Detect objects
-
Mounting Type:
-
screw mounting
-
Description:
-
capacitive sensor, Proximity Sensor
-
Model Number:
-
CKF30-20NO
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
AkuSense
-
Theory:
-
Optical sensor
-
Output:
-
NPN
-
Sensing distance:
-
2~20mm Adjust
-
Size:
-
M30
-
Material:
-
PBT
-
Operating Voltage:
-
10~30V DC(Ripple<10%)
-
Output Type:
-
NPN Open collector, NO
-
Switch frequency:
-
100Hz
-
Material active face:
-
PBT
-
Operating Temp:
-
-25℃~+70℃
-
Protection Degree:
-
IP67
Product Description
Cylindical(CK series)
1.Detect metal, plastic and liquid, etc
2.With reverse polarity, short circuit, surge and many other protection functions
3.Metal and plastic housing are available
Specification
|
Model
|
CKF30-20NO
|
|
Type
|
Shielded
|
|
Size
|
M30
|
|
Sensing distance
|
2~20mm Adjust
|
|
Material
|
PBT
|
|
Operating Voltage
|
10~30V DC(Ripple<10%)
|
|
Voltage drop
|
<2V
|
|
Load Current
|
300mA
|
|
No load current
|
<10mA
|
|
Leakage Current
|
<0.01mA
|
|
Output Type
|
NPN Open collector, NO
|
|
Switch frequency
|
100Hz
|
|
Response Time
|
1.5ms
|
|
Repeat accuracy
|
<5%(Sr)
|
|
Switch hysteresis
|
<15%(Sr)
|
|
Material active face
|
PBT
|
|
Operating Temp
|
-25℃~+70℃
|
|
Protection
|
Short-circuit Protection
|
|
Protection Degree
|
IP 67
|
|
Overload trip point
|
350mA
|
|
Connection
|
2M/3-wires cable
|
