Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
FZOLINK
-
Model Number:
-
JXZ-200A-A(C)
-
Product name:
-
Energy Storage Connector
-
Contact material:
-
Nickel Plated Copper
-
Shell material:
-
Nylon
-
Rated Voltage:
-
600V DC
-
Current:
-
120/150/200/300/400A
-
Color:
-
Red / Blcak
-
Wire SPEC.:
-
8mm²/10mm²/16mm²/25mm²
-
Temperature Range:
-
-40~125degrees
-
Terminal Type:
-
Binding post/Bolt
Quick Details
-
Type:
-
Energy Storage Connector
-
Application:
-
Power
-
Gender:
-
Male & female
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
FZOLINK
-
Model Number:
-
JXZ-200A-A(C)
-
Product name:
-
Energy Storage Connector
-
Contact material:
-
Nickel Plated Copper
-
Shell material:
-
Nylon
-
Rated Voltage:
-
600V DC
-
Current:
-
120/150/200/300/400A
-
Color:
-
Red / Blcak
-
Wire SPEC.:
-
8mm²/10mm²/16mm²/25mm²
-
Temperature Range:
-
-40~125degrees
-
Terminal Type:
-
Binding post/Bolt
More product options
Product Parameters
Features
1. Connector mating is convenient and fast, and blind mating can be realized.
2.
Positive and negative poles have key structure error prevention function and color vision function.
3.
It has good corrosion resistance and high temperature resistance, and can maintain stable connection performance in long-term use.
4.
The energy storage connector can withstand high current and high voltage to adapt to the high-power output and fast charge and discharge needs of energy storage devices.
|
Model Number:
|
JXZ-200A-A(C)
|
Terminal type
:
|
A:Binding post / C:Bolt
|
|
Rated (Max.):
|
120A/150A/200A/
300A/400A
|
Wiring Method
:
|
Crimp+M6/M8
thread Bolt-Type
|
|
Rated Voltage:
|
600V DC
|
Recommended usage:
|
≥200 times
|
|
Product
Color:
|
Red / Black
|
Working Temperature:
|
-40℃~+125℃
|
|
Contact Material:
|
Copper, Nickel plated
|
Housing Material:
|
Nylon
|
|
Protection class
:
|
IP54
|
Flame Retardant rating:
|
UL94 V-0
|
Drawings
Application scenario：
Electric vehicle charging pile
Solar power system
Power grid energy storage system
Wind power generation system
Home energy storage system
Industrial energy storage system
Electric vehicle connectivity
