Actual riding)
Height: 178cm&Weight: 95kg(
The model said it wasn't tough enough, and avoided)
Explore More Products
- Product Details
- {{item.text}}
Quick Details
-
Voltage:
-
48V
-
Power Supply:
-
Lithium Battery
-
Braking System:
-
Hydraulic Disc Brake (Hydraulic Brake Pad)
-
Battery Capacity:
-
40Ah
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Raider E-bikes
-
Model Number:
-
RaiderTrike-C201
-
Tire:
-
Kenda 26*3.0*2/20*3.0
-
Max Load:
-
300kgs
-
Charger:
-
54.6V 3A
-
N.W/G.W:
-
45/52KGS
-
Dimension Size:
-
2030*1380*1200mm
-
MOQ:
-
≥2 pcs
-
OEM/ODM:
-
Support
-
Logo:
-
Support
-
Supply Type:
-
Customize
Quick Details
-
Gears:
-
7 Speed
-
Frame Material:
-
Aluminum Alloy
-
Wheel Size:
-
26"*3.0*2&20"*3.0"
-
Voltage:
-
48V
-
Power Supply:
-
Lithium Battery
-
Braking System:
-
Hydraulic Disc Brake (Hydraulic Brake Pad)
-
Battery Capacity:
-
40Ah
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Raider E-bikes
-
Model Number:
-
RaiderTrike-C201
-
Tire:
-
Kenda 26*3.0*2/20*3.0
-
Max Load:
-
300kgs
-
Charger:
-
54.6V 3A
-
N.W/G.W:
-
45/52KGS
-
Dimension Size:
-
2030*1380*1200mm
-
MOQ:
-
≥2 pcs
-
OEM/ODM:
-
Support
-
Logo:
-
Support
-
Supply Type:
-
Customize
Products Description
|
Classify
|
Parts
|
Specifications
|
|
E-Parts
|
Battery
|
Bottom battery LG / Samsung / other high quality
|
|
|
Motor
|
Bafang Central motor/ HL 500w- 1000W front and rear hub motor
|
|
|
Controller
|
14-30A controller
|
|
|
Panel
|
LED / LCD panel
|
|
|
Throttle
|
thumb throttle
|
|
|
Charger
|
2 pieces of 110-240v AC 50-60HZ,54.6V3A N/A Standard
|
|
Frame&Fork
|
Frame
|
Alluminium alloy
|
|
|
Front fork
|
26 inch hydraulic shock absorber front fork
|
|
|
Finishment
|
Frame and fork painting matt black ( Customized color)
|
|
Gears system
|
Shift lever
|
SHIMANO, 7SP
|
|
Brakes
|
Brake levers
|
alloy levers, with cut-off-motor functions
|
|
|
Front brake
|
Hydraulic Dsic-brake
|
|
|
HRear brake
|
Hydraulic Disc-brake
|
|
|
Brake cables
|
Stainless cables, with BK casings
|
|
Wheels
|
Rims
|
26"*3.0*36H*13G*2&20"*3.0*36H*13G
|
|
|
Front hub
|
alloy, for disc -brake
|
|
|
Tires
|
26''×3.0 &20"*3.0 snow bike use
|
|
|
Inner tubes
|
26''×3.0 &20"*3.0snow bike use
|
|
|
Rim tapes
|
Cargo bike use
|
Bafang 750W Mid -Motor
You can easily carry 300 kg of goods forward (of course, considering the cost -effective, it is recommended that you choose our equally excellent front -wheel drive, more cost -effective)
Dual battery pack
Satisfy the long battery life and maintain power for a long time.
Can reach 1920WH-LG capacity
Side seats are roomier and more comfortable
The overall size of the additional seat: 900mm*800mm*1140mm
The installation of three wheels is free
The additional detachable parts are convenient for your different needs
Strong connection parts
Don't worry about the connection is not strong, it can withstand the gravity of 300kg is safe
Wider and bigger pedals
Satisfies the pedal position, it is also a safer support when you transport things
Roll over? that won't happen
Riding alone, we can play in various ways, but there will be no rollover
3 people, more happiness
3 people carry heavy loads, and the same riding is easy, safe and secure
The Trusted Cargo Carrier
FAQ
Q1 : Are you a real manufacturer? Can I visit your factory?
A : Yes! We are an electric bike manufacturer.We certainly welcome you to visit our factories anytime!
Q2 : How can i trust you ?
A :We are the legal certificate of Alibaba. Meanwhile, we can provide copies of our export and registration documents. Most importantly, we have 12 years of professional export experience in the production and OEM of electric bicycles.
Q3: How does your factory do regarding the quality control?
A:Staff are well trained!Every bike will be fully assembled and tested seriously before packing and shipping.
Q4: Do you offer the sample ?
A: sample is possible ,Just we need charge the sample fee accordingly.It can be returned for bulk orders.
Q5: Do you support customization of your products?Can we put our logo on the bikes?
A : Of course. We offer OEM/ODM service. You can make your own logo and style! Besides, we own so much data from different markets and industry. We can give you advice as well!
Our Advantages
1.
12 years of professional
export production experience in electric bicycles
2. OEM/ODM service: Size, RPM, Torque and Over Lock Dimension can be customized
2. OEM/ODM service: Size, RPM, Torque and Over Lock Dimension can be customized
3.
Years Warranty
except destructible test and artifically damage
4.
Competitive Price
because we're factory
