- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Wiliyoung
-
Model Number:
-
501010/ 401010/ 451010/ 451213/ 501012/ 501013
-
Battery Size:
-
5*10*10mm/ custom
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
10g
-
The charging ratio:
-
0.5C
-
The discharge rate:
-
1C
-
Type:
-
customized 3.7V 40mAh lipo battery
-
Size:
-
4*10*10mm/5*10*10mm/custom
-
Capacity:
-
40mAh/ 35mAh/ customized
-
Power:
-
0.148Wh/0.13Wh/custom
-
Certification:
-
UI1642, IEC62133, UN38.3,MSDS, KC, CE, BIS,ROHS,TUV etc., UN38.3, MSDS,KC, CB, IEC62133, ROSH
-
Custom Services:
-
Customized battery sizes/capacities/connectors/PCBs
-
Connectors:
-
JST/ SM/ Anserson/JR/ Molex...available
-
Wires/ Boards:
-
With/ without as your requests.
-
Protection:
-
Over charge,over discharge,over voltage,short circuit&high temperture.
-
Warranty:
-
12 months
Quick Details
-
Storage Type:
-
LiCoO2
-
Anode Material:
-
LCO
-
Application:
-
Toys, Consumer Electronics
-
Brand Name:
-
Wiliyoung
-
Model Number:
-
501010/ 401010/ 451010/ 451213/ 501012/ 501013
-
Battery Size:
-
5*10*10mm/ custom
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
10g
-
The charging ratio:
-
0.5C
-
The discharge rate:
-
1C
-
Type:
-
customized 3.7V 40mAh lipo battery
-
Size:
-
4*10*10mm/5*10*10mm/custom
-
Capacity:
-
40mAh/ 35mAh/ customized
-
Power:
-
0.148Wh/0.13Wh/custom
-
Certification:
-
UI1642, IEC62133, UN38.3,MSDS, KC, CE, BIS,ROHS,TUV etc., UN38.3, MSDS,KC, CB, IEC62133, ROSH
-
Custom Services:
-
Customized battery sizes/capacities/connectors/PCBs
-
Connectors:
-
JST/ SM/ Anserson/JR/ Molex...available
-
Wires/ Boards:
-
With/ without as your requests.
-
Protection:
-
Over charge,over discharge,over voltage,short circuit&high temperture.
-
Warranty:
-
12 months
Product Description
Specification
|
3.7V Lipo Battery Basic Information
|
|
|
|
Dimension
|
4*10*10mm/ 5*10*10mm/ customized
|
|
|
Nominal capacity
|
40mAh/ 35mAh/ customized
|
|
|
Power
|
0.148Wh/ 0.13Wh/ customized
|
|
|
Charge voltage
|
4.2V
|
|
|
Nominal voltage
|
3.7V
|
|
|
Full-charge voltage
|
4.2v
|
|
|
Ship out volatge
|
3.7-4.1v
|
|
|
Battery Specification
|
|
|
|
Standard charge
|
0.5C
|
|
|
Max charge
|
1.0C
|
|
|
Standard discharge current
|
0.5C
|
|
|
Max Standard discharge current
|
1.0C
|
|
|
Discharge cut-off voltage
|
2.75V or 3.0V
|
|
|
Charge temperature
|
0℃~45℃
|
|
|
Discharge temperature
|
-10℃~60℃
|
|
|
Storage temperature
|
-10℃~45℃
|
|
|
Battery recyle time
|
500 times
|
|
|
Warranty
|
12 Months
|
|
|
Certifications
|
UI1642, IEC62133, UN38.3, MSDS, KC, CE, BIS, ROHS, TUV etc.
|
|
Charging method
|
Built-in chips provide protection for over charge, over discharge, over voltage, short circuit and high temperture.
|
|
Charging method
|
Charge with constant current 0.5c to 4.2V. then chagre with constant voltage 4.2v till. until charge current is less than 0.01C
|
|
Application
|
Widely used in wireless devices, digital devices, intelligent wearable devices, digital medical devices, measuring instruments and other high-tech electronic products.
|
360° Custom Services
Customized Battery Packs
Customized Connectors
Customized PCBs
Customized Sizes& Capacities
|
Model
|
Capacity
|
Size
|
Voltage
|
Certifications
|
|
401010
|
35mAh
|
4*10*10mm
|
3.7V
|
MSDS, KC, CE, BIS
|
|
501010
|
40mAh
|
5*10*10mm
|
3.7V
|
UI1642, IEC62133, UN38.3, MSDS, KC, CE, BIS
|
|
451010
|
40mAh
|
4.5*10*10mm
|
3.7V
|
UI1642, IEC62133, UN38.3, MSDS, KC, CE, BIS
|
|
451213
|
40mAh
|
4.5*12*13mm
|
3.7V
|
IEC62133, UN38.3, MSDS, KC, CE
|
|
501012
|
40mAh
|
5*10*12mm
|
3.7V
|
UI1642, IEC62133, UN38.3, MSDS, KC, CE, BIS
|
|
501013
|
40mAh
|
5*10*13mm
|
3.7V
|
UN38.3, MSDS, KC, CE
|
Please contact us for more size/capacity.
↓
↓
↓
Production Flow
About US
Your reliable lithium battery solutions supplier.
1. Experienced R&D team since 2010.
2. 50,000,000 pcs annual production, 5 automatic production lines.
3. High popular for customized 3.7V lithium battery,.
4. Strictly QC team, testing equipment, with reliable after-sales service system.
5. Good comments, reputationand feedback from our satisfied customers.
Certifications
UI1642, IEC62133, UN38.3, MSDS, KC, CE, BIS, ROHS, TUV etc.
