Quick Details
-
Model Number:
-
LY-SS07
-
Max. Current:
-
0.3A
-
Mechanical Life:
-
10000 cycles
-
Type:
-
SS07
-
Rating:
-
300mA. 4V DC
-
Insulation resistance:
-
100MΩ max 100V DC
-
Dielectric strength:
-
250V AC for 1 min
-
Contact resistance:
-
700mΩ max
-
Operating temperature range:
-
-10℃ to +70℃
-
Lifetime:
-
10000Cycles min
-
Travel:
-
1.5±0.2mm
Quick Details
-
Max. Voltage:
-
50V
-
Place of Origin:
-
Guam
-
Brand Name:
-
LY
-
Model Number:
-
LY-SS07
-
Max. Current:
-
0.3A
-
Mechanical Life:
-
10000 cycles
-
Type:
-
SS07
-
Rating:
-
300mA. 4V DC
-
Insulation resistance:
-
100MΩ max 100V DC
-
Dielectric strength:
-
250V AC for 1 min
-
Contact resistance:
-
700mΩ max
-
Operating temperature range:
-
-10℃ to +70℃
-
Lifetime:
-
10000Cycles min
-
Travel:
-
1.5±0.2mm
|
Specification |
|
|
Items |
Standard |
|
Rating |
300mA 4V DC |
|
Insulation resistance |
100 MΩ max. 100V DC |
|
Dielectric strength |
250V AC for 1 min. |
|
Contact resistance |
70mΩ max. |
|
Operating temperature range |
-10°c to + 70 °C |
|
Lifetime |
10,000 Cycles min. |
|
Operating force |
120 ± 50gf 2C-2P: 180 ± 50gf |
|
Travel |
1.50 ± 0.2mm |
