Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
Yousui
-
Dimension(L*W*H):
-
1250*1900* 3150
-
Weight:
-
550kg
-
Warranty:
-
1 Year
-
Core Components:
-
Blades
-
Keywords:
-
self-propelled napier grass cutter corn silage harvesting machine
-
Model:
-
YS-1500
-
Color:
-
Red
-
Cutting width (mm):
-
1500mm
-
Power:
-
75hp
-
Used for:
-
Corn Stalk
-
Capacity:
-
0.4-0.5 Hectare /h
-
Function:
-
Cutting
Quick Details
-
Number of Rows:
-
1
-
Working Width(mm):
-
1500 mm
-
Tractor Power(HP):
-
50 - 120 HP
-
Place of Origin:
-
China
-
Brand Name:
-
Yousui
-
Dimension(L*W*H):
-
1250*1900* 3150
-
Weight:
-
550kg
-
Warranty:
-
1 Year
-
Core Components:
-
Blades
-
Keywords:
-
self-propelled napier grass cutter corn silage harvesting machine
-
Model:
-
YS-1500
-
Color:
-
Red
-
Cutting width (mm):
-
1500mm
-
Power:
-
75hp
-
Used for:
-
Corn Stalk
-
Capacity:
-
0.4-0.5 Hectare /h
-
Function:
-
Cutting
Agricultural self-propelled napier grass cutter corn silage harvesting machine
Introduction:
The Silage harvester matches with tractor or corn combine harvester.It can complete chopping,throwing and collecting continuously.It is suitable to chop erect or tiled corn straw,sorghum stalk or pasture with different mature period.
Features:
1.It applies bilateral transmission technology,the production efficiency is very high.
2.By adding the overloading clutch protective device,we solve the issue of straw jam during working.
3.The wearing resistance is stronger and prolong its life.Meanwhile,the chopping way is cylindrical.
4.Mine outer body can full 360 degree rotate.
Specification:
|
Model |
YS-1000 |
YS-1300 |
YS-1500 |
YS-1650 |
YS-1800 |
|
Harvesting width |
1m |
1.3m |
1.5m |
1.65m |
1.8m |
|
Power |
35-50HP |
50HP |
60HP |
75HP |
90HP |
|
Capacity (acres/h) |
≥3 |
≥4 |
≥5 |
≥6 |
≥7 |
|
Stubble height (mm) |
100-150 |
100-150 |
100-150 |
100-150 |
100-150 |
|
Recovery rate |
≥89% |
≥89% |
≥85% |
≥85% |
≥85% |
|
Throwing horizontal distance |
≥3m |
≥3m |
≥3m |
≥3m |
≥3 |
|
Stalk chopping length |
3-8cm |
3-8cm |
3-8cm |
3-8cm |
3-8cm |
|
Height of remaining stalk |
≥400mm |
≥400mm |
≥400mm |
≥400mm |
≥520mm |
|
Blades quantity |
30pcs |
30pcs |
40pcs |
46pcs |
48pcs |
|
Main shaft speed |
2160r/min |
2160r/min |
2160r/min |
2160r/min |
2160r/min |
|
Weight |
400kg |
450kg |
550kg |
680kg |
700kg |
|
Dimension (mm) |
1250*1350* 3150 |
1250*1650* 3150 |
1250*1900* 3150 |
1250*2000* 3150 |
1250*2150* 3150 |
