Quick Details
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
Tengka
-
Dimension(L*W*H):
-
515x450x490mm
-
Weight:
-
17
-
Rated power/speed:
-
3600
-
Certification:
-
CE
Quick Details
-
Displacement:
-
210cc
-
Emission Standard:
-
Euro 3
-
Power:
-
7HP
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
Tengka
-
Dimension(L*W*H):
-
515x450x490mm
-
Weight:
-
17
-
Rated power/speed:
-
3600
-
Certification:
-
CE
Products Details
|
ITEM
|
GP168F
|
GP168F-1
|
GP170F
|
GP188F
|
GP190F
|
||||
|
Engine Type
|
Air-cooled; 4-stroke; OHV; single cylinder
|
|
|
|
|
||||
|
Bore x Stoke (mm)
|
68x45
|
68x54
|
70x54
|
88x64
|
90x66
|
||||
|
Displacement (cc)
|
163
|
196
|
210
|
389
|
420
|
||||
|
compression Ratio
|
8.5 : 1
|
8.5 : 1
|
8.5 : 1
|
8.0 : 1
|
8.0 : 1
|
||||
|
Max.Power Output
|
(5.5HP) 4.1
|
(6.5HP) 4.8
|
(7.0HP) 5.1
|
(13HP) 9.6
|
(15HP) 1.1
|
||||
|
Rated Power Output (kw)
|
(4.0HP) 3.0
|
(5.8HP) 4.3
|
(6.0HP) 4.4
|
(13HP) 9.6
|
(11.7HP) 8.6
|
||||
|
Max.Torque (N.m)
|
11
|
13.2
|
14
|
26.5
|
28
|
||||
|
Ignition System
|
Transistor magneto
|
|
|
|
|
||||
|
Start System
|
Recoil / Electric
|
|
|
|
|
||||
|
Engine Oil Capacity (L)
|
0.6
|
0.6
|
0.6
|
1.1
|
1.1
|
||||
|
Fuel Capacity (L)
|
4
|
3.6
|
3.6
|
7
|
6.5
|
||||
|
Min. Consumption ot Fuel (g/kw.h)
|
360
|
360
|
360
|
325
|
325
|
||||
|
Power Take Off
|
Crankshaft or Camshaft
|
|
|
|
|
||||
|
Crankshaft Direction
|
Left
|
|
|
|
|
||||
|
Dimensions (LxWxH) (mm)
|
390x330x35
|
390x330x350
|
390x330x350
|
515x420x490
|
515x420x490
|
||||
|
Net Weight (kg)
|
15
|
16
|
17
|
31
|
32
|
||||
|
Air Cleaner
|
Semi-dry; Oil bath; Dual
|
|
|
|
|
||||
Product Paramenters
