Quick Details
-
Brand Name:
-
LONVILL
-
Product Name:
-
UHF RFID Reader
-
Dimensions:
-
107*107*24mm
-
Weight:
-
150g/250g
-
Interface:
-
USB HID/RS232
-
Output Power:
-
12.5dBm~26dBm (software adjustable)
-
Label Agreement:
-
ISO18000-6C (EPC GEN2)
-
Power Supply:
-
DC +5V
-
Keyword:
-
Uhf Rfid Reader 902MHz~928MHz
-
Color:
-
Black
-
Certification:
-
CE.ROHS.FCC
Quick Details
-
Frequency:
-
920~925MHz / 902~928MHz
-
Protocol:
-
ISO18000-6C (EPC GEN2)
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
LONVILL
-
Product Name:
-
UHF RFID Reader
-
Dimensions:
-
107*107*24mm
-
Weight:
-
150g/250g
-
Interface:
-
USB HID/RS232
-
Output Power:
-
12.5dBm~26dBm (software adjustable)
-
Label Agreement:
-
ISO18000-6C (EPC GEN2)
-
Power Supply:
-
DC +5V
-
Keyword:
-
Uhf Rfid Reader 902MHz~928MHz
-
Color:
-
Black
-
Certification:
-
CE.ROHS.FCC
Product Paramenters
Product Parameters
|
Working frequency:
|
National standard (920~925MHz)
American Standard (902~928MHz) Other multinational frequency standards (customized) |
|
Label Agreement:
|
ISO18000-6C (EPC GEN2)
|
|
Frequency hopping method:
|
Broad spectrum frequency hopping (FHSS) or fixed frequency that can be set by software;
|
|
Antenna parameters:
|
2dBi circular polarization antenna (built-in)
|
|
Output Power:
|
12.5dBm~26dBm (software adjustable)
|
|
Reading distance:
|
1.The maximum reading distance of the tag: 0.5m (related to factors such as transmit power, antenna type, tag type and application
environment) 2.Maximum distance to write tags: 0.2m (depending on factors such as transmit power, antenna type, tag type and application environment) |
|
Operating mode:
|
Active mode
Passive mode Answer mode (not recommended) |
|
Power interface:
|
DC +5V
|
|
Communication Interface:
|
1.USB virtual keyboard
2.USB virtual serial port (need to be customized) |
|
Operating temperature:
|
-20℃～55℃
|
|
storage temperature:
|
-40℃～85℃
|
|
size:
|
107*107*24mm
|
|
weight:
|
150g/250g
|
|
Power Adapter:
|
USB powered
|
|
Power cable:
|
Equipped
|
|
RS-232 signal line:
|
Equipped
|
|
Development kit:
|
Provide SDK
|
