Quick Details
-
specification:
-
UNS N04400/W.Nr 2.4360
-
standard:
-
ASTM/AISI/GB/ASME/DIN etc
-
certificate:
-
ISO9001/ROHS/BV
-
chemical composition:
-
nickel-based alloy
-
surface treatment:
-
smooth and bright
-
application:
-
marine fixtures and fasteners, chemical processing equipment
-
Property:
-
super alloy monel 400 wire
-
Product name:
-
Pure Nickel Wire
-
Packing:
-
1000kg/bag
Quick Details
-
Application:
-
Marine engineering,Gasoline and freshwater tanks
-
Place of Origin:
-
Jiangsu, China
-
Model No.:
-
monel 400
-
specification:
-
UNS N04400/W.Nr 2.4360
-
standard:
-
ASTM/AISI/GB/ASME/DIN etc
-
certificate:
-
ISO9001/ROHS/BV
-
chemical composition:
-
nickel-based alloy
-
surface treatment:
-
smooth and bright
-
application:
-
marine fixtures and fasteners, chemical processing equipment
-
Property:
-
super alloy monel 400 wire
-
Product name:
-
Pure Nickel Wire
-
Packing:
-
1000kg/bag
Uses Buyers Price Per Kg Np1 Np2 99.98% 99.6% 0.025 Mm Russian Pure Nickle Nickel Wire
Nickel-chromium alloy with high and stable resistance, corrosion resistance, surface oxidation resistance, e xcellent coil-forming ability.
Size dimension range:
Wire: 0.01-10mm
Ribbons: 0.05*0.2-2.0*6.0mm
Strip: 0.05*5.0-5.0*250mm
NiCr series: Cr10Ni90,Cr20Ni80, Cr30Ni70, Cr15Ni60, Cr20Ni35, Cr20Ni30
| Alloy Nomenclature Performance | Cr20Ni80 | Cr30Ni70 | Cr15Ni60 | Cr20Ni35 | Cr20Ni30 | |
| Main Chemical composition | Ni | Rest | Rest | 55.0-61.0 | 34.0-37.0 | 30.0-34.0 |
| Cr | 20.0-23.0 | 28.0-31.0 | 15.0-18.0 | 18.0-21.0 | 18.0-21.0 | |
| Fe | ≤1.0 | ≤1.0 | Rest | Rest | Rest | |
| Max. continuous service temp. of element(ºC) | 1200 | 1250 | 1150 | 1100 | 1100 | |
| Meltiing point ℃ | 1400 | 1380 | 1390 | 1390 | 1390 | |
| Resistivity at 20ºC (μΩ·m) | 1.09±0.05 | 1.18±0.05 | 1.12±0.05 | 1.00±0.05 | 1.04±0.05 | |
| Density(g/cm3) | 8.4 | 8.1 | 8.2 | 7.9 | 7.9 | |
| Thermal conductivity (KJ/m·h·ºC) | 60.3 | 45.2 | 45.2 | 43.8 | 43.8 | |
| Coefficient of lines expansion(α×10-6/ºC) | 18 | 17 | 17 | 19 | 19 | |
| Melting point approx.( ºC) | 1400 | 1380 | 1390 | 1390 | 1390 | |
| Elongation at rupture(%) | >20 | >20 | >20 | >20 | >20 | |
| Micrographic structure | Austenite | Austenite | Austenite | Austenite | Austenite | |
| Magnetic properties | Nonmagnetic | Nonmagnetic | Nonmagnetic | Weak magnetic | Weak magnetic | |
