Quick Details
-
Model Number:
-
BKQ-B200(II)
-
Place of Origin:
-
Shandong, China
-
Model:
-
BKQ-B200(II)
-
Capacity:
-
200L
-
Chamber Size(mm):
-
386*670
-
Working Pressure:
-
0.28MPa
-
Working Temp.:
-
150℃
-
Temperature Range:
-
105~136℃
-
Chamber Material:
-
SUS304
-
Timing range:
-
0~999min
-
Dynamic Pulse Exhaust Times:
-
0~9 times
-
Consumption:
-
5.5KW
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support
-
Brand Name:
-
BIOBASE
-
Model Number:
-
BKQ-B200(II)
-
Place of Origin:
-
Shandong, China
-
Model:
-
BKQ-B200(II)
-
Capacity:
-
200L
-
Chamber Size(mm):
-
386*670
-
Working Pressure:
-
0.28MPa
-
Working Temp.:
-
150℃
-
Temperature Range:
-
105~136℃
-
Chamber Material:
-
SUS304
-
Timing range:
-
0~999min
-
Dynamic Pulse Exhaust Times:
-
0~9 times
-
Consumption:
-
5.5KW
Product Description
Specification
|
Model
|
BKQ-B50(II)
|
BKQ-B75(II)
|
BKQ-B100(II)
|
BKQ-B120(II)
|
BKQ-B150(II)
|
BKQ-B200(II)
|
|||||
|
Capacity
|
50L
|
75L
|
100L
|
120L
|
150L
|
200L
|
|||||
|
Chamber size(mm)
|
φ386×500
|
φ386×682
|
φ386×875
|
φ386×1055
|
φ500*760
|
φ500*1000
|
|||||
|
Chamber material
|
304 medical stainless steel
|
|
|
|
|
|
|||||
|
Max designed
pressure |
0.28Mpa
|
|
|
|
|
|
|||||
|
Max designed temp
|
150℃
|
|
|
|
|
|
|||||
|
Working pressure
|
0.175MPa
|
|
|
|
0.217MPa
|
|
|||||
|
Working temp.
|
105~136℃
|
|
|
|
50~134℃
|
|
|||||
|
Temp. accuracy
|
±0.1℃
|
|
|
|
|
|
|||||
|
Timing range
|
0~999min
|
|
|
|
|
|
|||||
|
Dynamic pulse
exhaust times |
0~9 times
|
|
|
|
|
|
|||||
|
Dynamic pulse
exhaust temp. |
105~134℃
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|||||
|
Dissolution temp.
range |
60~100℃(programmable)
|
|
|
|
|
|
|||||
|
Temp. holding range
|
40~60℃(programmable)
|
|
|
|
|
|
|||||
|
Power supply
|
110/220V, 50/60Hz
|
|
|
220V, 50/60Hz
|
380V, 50Hz
|
|
|||||
|
Power consumption
|
4.4KW
|
4.7KW
|
5.2KW
|
5.2KW
|
6KW
|
|
|||||
|
SS basket
|
1 pc
|
2pcs
|
2pcs
|
3pcs
|
3 pcs
|
4pcs
|
|||||
|
External size(mm)
|
550x640x970
|
550x640x1070
|
550x640x1270
|
550x640x1370
|
715*720*1350
|
715*720*1550
|
|||||
|
Packing size(mm)
|
765*700*1150
|
765*700*1260
|
765*700*1450
|
765*700*1650
|
760*800*1500
|
760*800*1690
|
|||||
|
Gross weight(kg)
|
110
|
114
|
135
|
160
|
230
|
|
|||||
