Quick Details
-
Interface Type:
-
SATA III
-
Brand Name:
-
KingSpec
-
Model Number:
-
MSH-64
-
Place of Origin:
-
Guangdong, China
-
Controller:
-
SM2244LT
-
NAND Type:
-
MLC
-
Access Time:
-
0.15ms
-
MTBF:
-
1,000,000 hours
-
Certifications:
-
CE, FCC, RoHS, KC ,REACH
-
Width:
-
49mm
-
Length:
-
54mm
-
Operating Tempreture:
-
0~70℃
-
Warranty:
-
3 years
Quick Details
-
Application:
-
Laptop|Desktop|Pos System|Motherboard
-
Type:
-
Internal
-
Style:
-
SSD
-
Interface Type:
-
SATA III
-
Brand Name:
-
KingSpec
-
Model Number:
-
MSH-64
-
Place of Origin:
-
Guangdong, China
-
Controller:
-
SM2244LT
-
NAND Type:
-
MLC
-
Access Time:
-
0.15ms
-
MTBF:
-
1,000,000 hours
-
Certifications:
-
CE, FCC, RoHS, KC ,REACH
-
Width:
-
49mm
-
Length:
-
54mm
-
Operating Tempreture:
-
0~70℃
-
Warranty:
-
3 years
Definition of Solid State Drive
Solid State Drives, which use flash memory instead of a hard-drive platter to store date.
Old computers had a habit of spitting files and spreading the parts all over your hard drives, but modern ones don’t do this as much. Not even close, a bimonthly pass with a capable Defragger can help you maintain peak performance on a heavily used hard drive.Data transfer to and from solid-state drives is much faster than electromechanical disk drives. Seek time and latency are also substantially reduced. Users typically enjoy much faster boot times as well.
In general, SSDs are also more durable and much quieter, with no moving parts to break or spin up or down. SSDs do, however, have slower write times and a set life expectancy, as there is a finite number of erase/write cycles before performance becomes erratic.
Advantages of Solid State Drive:
1. Quick response and high read/write speed
2.Silent mode
3.Low power consumption and low heat.
4.None mechanical breakdown
5.Can work under wider range tempreture, 0~70℃
6.Lighter, smaller and more portable.
7.Shockproof and drop resistance.
Our products’Competitive Advantage:
1)Original brand NAND Flash
2)Fast read/write speed, faster application load times
3)High reliability, data stability
4)Low energy consumption
5)Anti-shock, anti-dust, noiseless, superior security
6)Shockproof, rugged design safe and high stability and reliability
|
Model |
MSH-64 | |
|
General |
Form factor |
49.0mm x 54.0mm x 4.0mm |
|
Interface |
7+15pin SATA III(6Gbps) |
|
|
Performance |
Capacity |
8G / 16G / 32G/ 64GB / 128GB |
|
Max Sustained Read |
147MB/S|220MB/S|365MB/S|491MB/S|500MB/S |
|
|
Max Sustained Write |
18MB/S|28MB/S|46MB/S|84MB/S|140MB/S |
|
|
4KB Random Read / Write IOPS |
14000/19000 |
|
|
4KB Sequential Read/Write IOPS |
23000/25000 |
|
|
Average Access time |
0.15ms |
|
|
Storage Media |
NAND Flash |
MLC |
|
Power Consumption |
input Voltage |
5V (±5%) |
|
Idle |
1.70W |
|
|
Standby |
0.50W |
|
|
Reliability& Endurance |
Write endurance |
8years @100GBytes write and erase per day at 32GB |
|
Read endurance |
unlimited |
|
|
Wear-Leveling Algorithm |
Dynamic and static wear-leveling |
|
|
Data Retention |
10years at 25ºC |
|
|
MTBF |
1,000,000hours |
|
|
ECC |
Supports BCH 16/24/40 bits ECC |
|
|
Bad Block Management |
Auto Bad Block Management in system |
|
|
Environment |
Operating Temperature |
Commerical Grade:0~70°C /Industrial Grade:-40~85°C |
|
Ambient Humidity |
5-95% |
|
|
Warranty |
MLC:3years, SLC:5years |
|
|
Software and Management |
Trim support |
Yes |
|
Smart support |
Yes |
|
|
NCQ support |
Yes |
|
|
RADIO support |
Yes |
|
|
Available unit |
Available |
NO EOL |
|
Testing Platform |
CPU: Intel® Core(TM) i5-2400 CPU @ 3.10GHz Chipset: Intel® Z68 Express Chipset Memory: Kingston KHX1600C9D3C1K2/4GX OS: Microsoft Windows 7 Professional 64-bit AHCI Driver: Server Express Chipset SATA AHCI Controller BIOS Settings: AHCI Mode |
|
|
Testing Software |
PC Mark,CrystalDiskMark v3.0 ,AS SSD Benchmark,HD Tune PRO 3.50 |
|
|
Physical Dimensions & Weight |
Height(mm) |
4.00+/-0.1 |
|
Width(mm) |
49.00+/-0.15 |
|
|
Length(mm) |
54.00+/-0.15 |
|
|
Weight(g) |
TDB |
|
