High Quality Hot Sale SKT90S Wide-body Dump Truck Mining Truck 50 Ton loading Capacity

SKT90S wide-body dump truck independently developed by Heavy Equipment integrated the technologies of “wide-body mining truck” and “classic mining truck” and made special upgrades for critical parts, including frame, suspension, steering system, and cab, to offer the customers with allnew mining transport products of h i g h c o s t - p e r f o r m a n c e , h i g h attendance rate, and high safety.

High-Strength Frame

The all-new designed low-stress and high-strength frame effectively prevents the fatigue breakage of frame and reduce the overall stress level by 51% compared with competing products.

Hydro-pneumatic suspension

The hydro-pneumatic suspension technology is applied to replace the traditional leaf spring structure, remarkably improve the life and comfort of the machine, thoroughly solve the frequent breakage problem of front suspension leaf springs in the industry, and promote the attendance rate of the machine. The hydro-pneumatic suspension features excellent shock-absorbing and damping performance to remarkably improve the load application of frame and prolong the life of frame.

Full-hydraulic Steering+Emergency Steering

The full-hydraulic steering makes the steering easier and safer. The full-hydraulic steering design concept of traditional mining truck is applied to solve the industry’s heavy steering problem due to the heavy truck type mechanical steering. In addition, the emergency steering device is installed to solve the presently industry’s safety accidents due to steering failure during the emergency braking in event of power failure of the machine.

Intelligent Electric System

The “Two-in-one” electronic control module features high intelligence and incorporates the electric malfunction self-diagnosis to solve the customers' actual troubleshooting difficulties. It’s equipped with 10” large central control screen, reversing camera, and mobile phone Bluetooth connectivity and is compatible with the mine intelligent management system. The built-in GPS module enables the effective monitoring on the running status of machine.

Hydraulic Retarder

The automatic transmission is easy to operate,and equipped with retarder, which can solve the problem that the braking force of the vehicle braking system drops seriously due to the heat recession when trucks go downhill with heavy load, so as to ensure the braking safety of the whole machine.

All-new Appearance

The all-new interior and exterior modeling features more overall fullness feeling and brings about better visual impact. The airtightness of the cab is improved to achieve better sound-proof and dust-proof performance. The reasonable human-machine arrangement improves the operating comfort.

Specifications

Main parameter	Value
Engine power	390kW.530HP@2100HP
Transmission	FC6A250DPR
Stowed capacity of cargo body	38m³
Axle load	25T+35T+35T
Rated loading capacity	60T
Maximum Gross Mass of Vehicle	92T
Steering type	Full-hydraulic + emergency steering
Suspension structure	Front hydraulic/ pneumatic suspension + rear leaf spring suspension
Tyre	16.00R25 Wire Tire
Weight parameter	kg	1b
Net Weight of Truck	32,000	70,548
Rated Loading capacity	60,000	132,000
Maximum gross weight of vehicle	92,000	202,825
Optional equipment	Details
Tires	16.00R25 Wire Tyre (Tubeless)
V-shape Dump Body	Dump Body with Tail gate applicable for Large size material,o>500mm
Brake Cooling Sprayer	Applicable for long-distance heavy-load downslope driving condition.
Left Hand Drive Cabin	Export according to customer's requriement
Side Guards	Protect fuel tank and gasholder etc. from side collision
Automatic Lubricaiton System	Lubricating oil automatically filled to each filling point
