Quick Details
-
Brand Name:
-
AOYI
-
Model Number:
-
HN-DP3-VM
-
Supply Voltage:
-
220V(85% to 110%)
-
Operating Temperature:
-
0℃ to 40℃
-
Dimensions:
-
98 x 50 x 7 (mm)
-
Measure Precision:
-
±0.5% ±1Word
-
Application Environment:
-
0℃ to 40℃
-
Power Loss:
-
3.5W
-
Relative Humidity:
-
<85%
Quick Details
-
Measuring Range:
-
for customization
-
Accuracy Class:
-
0.5 class
-
Place of Origin:
-
China
-
Brand Name:
-
AOYI
-
Model Number:
-
HN-DP3-VM
-
Supply Voltage:
-
220V(85% to 110%)
-
Operating Temperature:
-
0℃ to 40℃
-
Dimensions:
-
98 x 50 x 7 (mm)
-
Measure Precision:
-
±0.5% ±1Word
-
Application Environment:
-
0℃ to 40℃
-
Power Loss:
-
3.5W
-
Relative Humidity:
-
<85%
1 measuring range :DC volt meter HN-DP3-VM DC volt meter digital volt amp meter.
2 accuracy: ±0.5%FS ±2 words(thermometer ±1%FS ±2 words).
3 sampling rate: about 3 times/s.
4 display mode: three-digit semi-LED digital tube display.
5 resolution: one word at the end.
6 auxiliary power supply: AC220V±10%(other power supplies can be customized).
7 auxiliary power consumption: 3VA.
8 overflow indication: the highest digit displays 1 or -1,and the remaining digit is hidden).
9 dc gauge polarity indicator: negative signal automatically displays "-",positive signal does not show.
10 working conditions: temperature-10~50℃;humidity-85%RH without corrosive gas.
2 When adjusting the potentiometer with measuring range or RANGE,change the measurement display value of the meter(it is not recommended to adjust the potentiometer if there is no standard instrument.)
3 measuring range selection: Different instrument range can be obtained according to the position of the plug cap on the display board.The relationship between the inserted position of the two interpolation amplitudes and the second point and the measuring range is shown in the following table(DP48 does not support this function).
