Big bottle cold alcohol vending machine with elevator function

Big bottle cold alcohol vending machine with elevator function

FOB Reference Price: Get Latest Price

≥2 Pieces

US $3280

≥50 Pieces

US $3120

≥100 Pieces

US $3010

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Warranty:: 3 years

Place of Origin:: Guangdong, China

Brand Name:: 9Steps

Power:: 120-600W

Product name:: alcohol vending machine

Payment System:: cash and cashless system

Color:: white

Application:: 9Steps android app

Capacity:: 300-540pcs

Certificate:: CE FCC ROHS ISO

Weight:: 275kg

Touch screen:: 21.5inch capacitive

Cooling system:: R134a MSDS refrigeration

Dispenses:: elevator option

Quick Details

Type:: Vending Machines

Dimension:: L1250*W890*H1935mm

After-sales Service Provided:: Video technical support, Free spare parts, Online support

Warranty:: 3 years

Place of Origin:: Guangdong, China

Brand Name:: 9Steps

Power:: 120-600W

Product name:: alcohol vending machine

Payment System:: cash and cashless system

Color:: white

Application:: 9Steps android app

Capacity:: 300-540pcs

Certificate:: CE FCC ROHS ISO

Weight:: 275kg

Touch screen:: 21.5inch capacitive

Cooling system:: R134a MSDS refrigeration

Dispenses:: elevator option

Product Description

Product Name	Big bottle cold alcohol vending machine with elevator function
Material	21.5-55inch touch screen + metal case+cash machine/cashless machine/elevator/refrigeration options
Package	exporting wooden case with pallet,package size 13509102100mm,275kg/pc
General Specification	Motherboard	Android RK3288
		RAM	2G
		Storage Memory	8G
	General Specification	OS	Android /7.1
		Network	Gigabit Network
		Lane	Standard 6 rows * 9columns, 54*10 cargo lanes (adjustable)
		Slot Capacity	About 210pcs-540pcs（adjustable）
		Payment Method	ICT banknotes cash accpeter+ card pos with NFC fucntion
		Subassembly	Cash accepter with bill change fucntion
		Optional	1. Temperature control system: high-efficiency and energy-saving compressor, support timing switch, free control of temperature 2. Printer (optional) 3. Coins and cash modules (optional) 4. Scanner (optional)
Panel Specification	Screen	21.5 Inch IR touch screen
		Screen type	TFT-LCD
		Backlight Type	WLED
		Visual Size	477mm269mm（HV）
		Resolution	1920*1080
		Contrast	3000:1
		Perspective	H:178°, V:178°
		Brightness	250nits（Non touch），225nits（Touch）
		Touch Technology	Capacitance Touch
		Touch Points	10 Points
		Operating Voltage	DC 5v
		Operating Temperature	0°C ~ 40°C, 20% ~ 80% RH.
		Storage Temperature	-20°C~ 60°C, 10% ~ 95% RH
		Interface Type	VGA , HDMI，USB，LAN
Motherboard Parameters	Processor	RK3288 Quad Corel.8G
		Chipset	HZ cortex-A17
		Extension Interface	Support TF Card expansion
		Display	GPU Mail-T764
		Memory Type	Built-in EMMC，Max 64GB Optional
		USB Interface	2USB HOST,4USB Port
		Output	HDMI Output ,EDP Output, LVDS Output, Audio Output
		Timer Switch	Support
		RTC Clock	Support
Optional	Printers	Support
		Scanner	Support
		Camera	Support
		Others	USB or MDB port

9 steps Big bottle cold alcohol vending machine with elevator function support single cabinet or double design, Single cabinet 9 aisles *6 layers*10 slots,capacity max 600pcs commodities, 60 kinds of commodities can be vending in one single cabinet snack vending machine.this batch snacks vending machines to Peru Callao,clients install payment system and make second software development by themselves. Our alcohol Beverage Vending Machines are designed with the latest technology, ensuring a seamless and hassle-free experience for our customers. They feature a user-friendly interface that allows you to easily navigate through a
range of products and make your selection with just a few taps.
