Quick Details
-
Brand Name:
-
XMK
-
Model Number:
-
Description Dependent Details Page
-
Place of Origin:
-
Jiangsu, China
-
Product name:
-
Slewing Bearing
-
Material:
-
50Mn 42CrMo
-
Brand:
-
XMK
-
Service:
-
OEM Customized Services
-
Warranty:
-
12 Months
-
OEM:
-
Accepet
-
Quality:
-
High-Quality
-
HARDNESS:
-
Quenching
-
Application:
-
Construction Machinery
Quick Details
-
Applicable Industries:
-
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company, Other
-
Feature:
-
Four Point Contact
-
Seals Type:
-
Nitrile Rubber, Labyrinth
-
Brand Name:
-
XMK
-
Model Number:
-
Description Dependent Details Page
-
Place of Origin:
-
Jiangsu, China
-
Product name:
-
Slewing Bearing
-
Material:
-
50Mn 42CrMo
-
Brand:
-
XMK
-
Service:
-
OEM Customized Services
-
Warranty:
-
12 Months
-
OEM:
-
Accepet
-
Quality:
-
High-Quality
-
HARDNESS:
-
Quenching
-
Application:
-
Construction Machinery
Product Parameters
Xuzhou XMK Slewing Bearing Co., Ltd. is a professional manufacturer and exporter of slewing bearing/slewing ring/slew circle and slewing drives/slew drive, which are mainly applied in port machinery, mining machinery, welding machinery, construction vehicles, modular vehicles, single or dual axis solar tracking systems, and small wind power systems etc.
By adopting slewing bearing as its core component,slewing drive can bear axial force, radial force and tilting moment simultaneously. Slewing drive is widely applied in modular trailers, all types of cranes, aerial working platform, solar tracking systems and wind power systems.
Electric and planetary gearboxes can be designed according to customer's requirment.Slewing drive has the advantage for saving space in facilities,max load capacity in a compact design,extensive lifespan, reduced maintenance costs.
|
Raceway center diameter
|
Plane deviation of mounting bracket P (mm)
|
|
|
||
|
DL(mm)
|
Single row four ball
|
Double row ball
|
Cross roller
|
||
|
~1000
|
0.15
|
0.2
|
0.1
|
||
|
>1000~1500
|
0.19
|
0.25
|
0.12
|
||
|
>1500~2000
|
0.22
|
0.3
|
0.15
|
||
|
>2000~2500
|
0.25
|
0.35
|
0.17
|
||
|
>2500~4000
|
0.3
|
0.4
|
0.2
|
||
|
>4000~6000
|
0.4
|
0.5
|
0.3
|
||
|
>6000~8000
|
0.5
|
0.6
|
0.4
|
||
|
Identification number
|
Inner diameter
/D(mm)
|
Outer diameter
/D(mm)
|
Width/B(mm)
|
Mounting holes/nB
|
Chamfer/R(min)
|
|
XMK080168
|
130
|
205
|
25.4
|
12
|
1.1
|
|
XMK080188
|
150
|
225
|
25.4
|
16
|
1.1
|
|
XMK080218
|
180
|
255
|
25.4
|
20
|
1.1
|
|
XMK080258
|
220
|
295
|
25.4
|
24
|
1.5
|
|
XMK080318
|
280
|
355
|
25.4
|
28
|
1.5
|
|
XMK080398
|
360
|
435
|
25.4
|
36
|
2
|
|
XMK140414
|
344
|
484
|
56
|
24
|
2
|
|
XMK140544
|
474
|
614
|
56
|
32
|
2.5
|
|
XMK140644
|
574
|
714
|
56
|
36
|
2.5
|
|
XMK140744
|
674
|
814
|
56
|
40
|
3
|
|
XMK140844
|
744
|
914
|
56
|
40
|
3
|
|
XMK140944
|
874
|
1014
|
56
|
44
|
3
|
|
XMK141094
|
1024
|
1164
|
56
|
48
|
4
|
Product Details
Gear Heat Treatment:
Rotary support bearings typically have gears on one of the rings to transmit power or torque. The heat treatment state of gears is usually either through hardening or quenching and tempering. Depending on the application, gears can also undergo gear induction hardening. Gear induction hardening can be further divided into tooth surface and tooth root hardening, as well as tooth surface hardening.
Product Application
Products Worth Recommending
Customer Trust
Factory Strength
Packing & Delivery
Previous Projects
Xuzhou XMK Slewing Bearing Co., Ltd. was founded in 2007, located in China's construction machinery base -- Xuzhou City, Jiangsu Province. Is a professional engaged in slewing bearing technology research and development and manufacturing of professional manufacturers. With the design, manufacture, test single volleyball type, cross roller type, double row ball type, double volleyball type, ball and column combined type, three row roller slewing bearing comprehensive development ability. The company has good facilities, strong production capacity, strong technical force, a variety of testing means complete, and has obtained a variety of certificates and honors.
The company has seven series of slewing bearing series production technology, the production of slewing bearing raceway center diameter 200-5000mm, a variety of standard and non-standard specifications of slewing bearing, with the ability to produce more than 1000 different specifications of slewing bearing models, and exported to Europe, America, Asia and other countries and regions. Products are widely used in engineering machinery, construction machinery, mining machinery, amusement equipment, ships, ports, petroleum, chemical, light industry, food, aviation, military, instrument and other industries. It has the characteristics of compact structure, light weight, good rigidity, stable operation, high precision, safety and reliability.
Xuzhou XMK Slewing Bearing Co., Ltd. will provide customers with high quality products with safe and reliable design, meticulous manufacturing, continuous innovation technology, modern business philosophy and timely and effective service. Strive to exceed the industry standards, beyond customer expectations, to be honest and trustworthy goodwill, with the majority of customers to win the world.
Q: Are you a factory or trading company?
A: As a professional manufacturer, we have own factory and warehouse.
Q: Why choose us?
A: With more than 15 years' experience in manufacturing slewing bearings, we exported our products to many countries and provided 300 sets of slewing bearings to participate in the construction of Hong Kong-Zhuhai-Macao Bridge.
Q: How can we guarantee quality?
A: We make our products by forging so as to ensure their hardness. Meanwhile, we always make a final Inspection before shipment.
Q: Do you provide samples?
A: No, we are so sorry that we can't provide samples for you because the cost is too high.
Q: What services can you offer?
A: 12 months warranty, professional advice, OEM, 1 piece MOQ.
Q: What is your terms of packing?
A: We provide packing as you need such as wooden boxes. However, no matter what kind of packing, you have to pay the extra charges.
Q: What about lead time?
A: It is according to quantity. Generally, it is 5-10 days if the goods are in stock, it is 15-30 days if the goods are not in stock.
Q: What is your terms of payment?
A:Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance, balance before shipment.
