Widely used in auto parts, electronic appliances, kitchen appliances, tractors, motorcycles, aerospace, aviation, ships, hardware products.
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Tsinfa
-
Year:
-
2020
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
2300*1200*2900
-
Weight (T):
-
9.5 T
-
Model Number:
-
TPS-630
-
Motor Power (kw):
-
18 kw
-
CNC or Not:
-
Normal
-
Power Source:
-
Hydraulic
-
Weight:
-
9500KG
-
Color:
-
Customizable
-
Capacity:
-
6300KN
-
Certification:
-
CE
Quick Details
-
Machine Type:
-
H Frame Hydraulic Press
-
Return Force (kN):
-
1000 kN
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Tsinfa
-
Year:
-
2020
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
2300*1200*2900
-
Weight (T):
-
9.5 T
-
Model Number:
-
TPS-630
-
Motor Power (kw):
-
18 kw
-
CNC or Not:
-
Normal
-
Power Source:
-
Hydraulic
-
Weight:
-
9500KG
-
Color:
-
Customizable
-
Capacity:
-
6300KN
-
Certification:
-
CE
Products Description
Application
TPS Series Hydraulic Press can assemble, disassemble, straightening, calendering, pressing, stretching, bending and punching of machine parts. Each hydraulic press from Tsinfa Cnc equipment combines an industry-leading design with a thick, fully-welded steel plate frame. We build every hydraulic press to provide fine control and to save you time and effort—throughout many years of productivity.
TPS Series Hydraulic Press can assemble, disassemble, straightening, calendering, pressing, stretching, bending and punching of machine parts. Each hydraulic press from Tsinfa Cnc equipment combines an industry-leading design with a thick, fully-welded steel plate frame. We build every hydraulic press to provide fine control and to save you time and effort—throughout many years of productivity.
Ranging from
10 to 10000 tons
in capacity, our hydraulic presses will handle all the force you can throw at them. Choose a hydraulic press (for added power) or a pneumatic shop press (air-powered, typically with lighter capacities) or hand operated h-frame shop press.
We can customize according to your request, for example, enlarge the workbench, let the worktable move, add two cylinders and so on
Main Feature
1.Actually realize one machine to use more.
2.This series uses the Italian cnk and the CBZ oil pump two pumps to combine the oil, compared with the traditional hydraulic machine energy saving more than 60%, the efficiency increases 2-3 times.
3.Has the small volume, the pressure is high, the structure is simple, the weight is light.
4.Worktable can move up and down, greatly expanding the machine opening and closing height, more convenient to use.
We can customize according to your request, for example, enlarge the workbench, let the worktable move, add two cylinders and so on
Main Feature
1.Actually realize one machine to use more.
2.This series uses the Italian cnk and the CBZ oil pump two pumps to combine the oil, compared with the traditional hydraulic machine energy saving more than 60%, the efficiency increases 2-3 times.
3.Has the small volume, the pressure is high, the structure is simple, the weight is light.
4.Worktable can move up and down, greatly expanding the machine opening and closing height, more convenient to use.
Product Paramenters
|
Model
|
TPS-200
|
TPS-300
|
TPS-400
|
TPS-500
|
TPS-630
|
|
Capacity (kn)
|
2000
|
3000
|
4000
|
5000
|
6300
|
|
Pressure (MPa)
|
25
|
25
|
25
|
25
|
25
|
|
Travel ( mm)
|
300+405
|
300+405
|
300+405
|
300+405
|
400+405
|
|
Table Size ( mm )
|
980 x 500
|
700×1200
|
800×1200
|
900×1200
|
1000×1200
|
|
Dimension (mm)
|
1940x950x2350
|
2100x950x2700
|
2300×1000x2900
|
2300×1000x2900
|
2300×1200x2900
|
|
|
900x800×1060
|
1100x1200x1350
|
1100x1200x1360
|
1100x1200x1350
|
1100x1200x1350
|
|
Weight ( kg)
|
2200
|
4200
|
5500
|
6500
|
9500
|
