Technical
|
|
|
|
FDD LTE
|
3GPP Release8, Download 100Mbps, Upload 50Mbps@20M bandwidth
|
|
|
DC-HPSA+
|
3GPP Release8, category 24,download speed up to 42 Mbps
|
|
|
HPSA+
|
3GPP Release7, category 14,download speed up to 21.6Mbps
|
|
|
UMTS
|
3GPP Release4,download/upoad speed up to384 Kbps
|
|
|
EDGE
|
3GPP Release4,class 12, download speed up to 237 Kbps
|
|
|
GPRS
|
3GPP Release4, class 10,download speed up to 85.6 Kbps
|
|
|
Band Frequency
|
|
|
|
GSM/GPRS/EDGE
|
850/900/1800/1900 MHz
|
|
|
UMTS
|
900/1900/2100MHz
|
|
|
LTE-TDD
|
B38 B40
|
|
|
LTE FDD
|
(B1 B3 B5 B7 B20 )(optional)
|
|
|
EV-DO
|
BC0
|
|
|
Power
|
|
|
|
WCDMA
|
Power Class 3
|
|
|
GSM/EDGE: 850/900/1800/1900
|
Power Class 4/Power Class E2
|
|
|
External Port
|
|
|
|
Main antenna
|
supported, internal antenna
|
|
|
Diversity Antenna
|
all frequency supported, internal, bracket antenna, nornal antenna with high frequency
|
|
|
MIMO
|
all frequency supported, internal, bracket antenna, nornal antenna with high frequency
|
|
|
USB type
|
standard USB2.0
|
|
|
USB speed
|
high speed USB 2.0
|
|
|
Power supply
|
USB
|
|
|
Micro-SD slot
|
2 in 1 port
|
|
|
SIM/USIM
|
Standard SIM port, compatible with 3GPP 32.101 and 32.102,1.8V/2.85V
|
|
|
AT Command port
|
Support 3GPP TS 27.005 and 3GPP TS27.007
|
|
|
|
Color Flashing Cycle: Searching Network
Red Slow Flashing: Abnormal of (U)SIM card or no network
Luminous continuously: Data transmission
Green: LTE
Blue: HSPA /HSPA+(14.4M/21M/42M)
Purple: UMTS/ EVDO
Yellow: EDGE/GPRS
|
|
|
Languages supported
|
English/Chinese, more languages can be customized
|
|
|
Free CD auto Installation mode
|
supported
|
|
|
OS supported
|
Windows XP(SP2)/ VISTA / WINDOWS7(32bit/64bit) WINDOWS 8 8.1
|
|
|
RAM
|
NandFlash 1G
|
|
|
hardware platform
|
MDM9200/MDM9600
|
|
|
WIFI
|
|
|
|
|
Built-in 4G/3G/2G & WIFI antenna
WIFI Antenna Gain: -1dbi
WIFI Antenna Sensitivity:
|
|
|
|
Power Consumption
Input Voltage: 5V/1A
Max Power consumption: <2W
|
|
|
WiFi Standard
|
802.11b/g/n, speed up to 72Mbps
|
|
|
WiFi Frequency
|
2412MHz-2472MHz
|
|
|
WiFi user max
|
10
|
|
|
Working Temperature
|
-20 to 70°C
|
|
|
Working Humidity
|
10%-85% RH
|
|
|
Storage Temperature
|
-40 to 85°C
|
|
|
Storage Humidity
|
5%-90% RH
|
|
|
Additional function
|
|
|
|
Micro-SD card
|
supported, up to 32GByte
|
|
|
Certification
|
|
|
|
ROHS
|
pproved
|
|
|
Microsoft WHQL
|
pproved
|
|
|
others
|
customization available
|
|
|
Dimensions
|
|
|
|
95mm*34mm*10mm
|
|
|
