Quick Details
-
Output Current:
-
32a
-
Output Power:
-
11.5kW
-
Input Voltage:
-
240Vac±15%
-
Product name:
-
EV Charger Station
-
Charging Port:
-
Type 1
-
Certificate:
-
CE ROHS FCC
-
Warranty:
-
12 Months
-
Use environment:
-
indoor / outdoor
-
Cable length:
-
5 Meters(UL/TPU)
-
Protection grade:
-
IP65
-
Single package size:
-
54*32*25 cm
-
Standard:
-
IEC 62196-2 IEC 61851-1
-
Leakage protection:
-
A
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Ovrod
-
Interface Standard:
-
Type 1
-
Output Current:
-
32a
-
Output Power:
-
11.5kW
-
Input Voltage:
-
240Vac±15%
-
Product name:
-
EV Charger Station
-
Charging Port:
-
Type 1
-
Certificate:
-
CE ROHS FCC
-
Warranty:
-
12 Months
-
Use environment:
-
indoor / outdoor
-
Cable length:
-
5 Meters(UL/TPU)
-
Protection grade:
-
IP65
-
Single package size:
-
54*32*25 cm
-
Standard:
-
IEC 62196-2 IEC 61851-1
-
Leakage protection:
-
A
Details Images
Product Paramenters
|
Output
|
Output voltage
|
AC 220V
|
|
|
Output current
|
16A/32A/48A
|
|
|
Rated power
|
7KW/11KW/22KW
|
|
User interface
|
Cable length
|
5M
|
|
|
Body size
|
355*250*95 mm
|
|
|
LED indicator
|
Green/blue/red (blue - standby; green - charger connected to the vehicle, flashing - charging; red - abnormal)
|
|
|
Emergency stop
|
include
|
|
Start-up mode
|
Plug-and-Play
|
Yes
|
|
|
RFID Reader
|
—
|
|
Network
|
4G
|
Yes
|
|
|
RJ45
|
—
|
|
|
Bluetooth/WiFi
|
Yes
|
|
Security
|
RCD
|
A+DC6mA
|
|
|
Ingress Protection
|
IP65
|
|
|
Surge Protection
|
IK10
|
|
|
Electrical Protection
|
Overvoltage protection, undervoltage protection, grounding protection, lightning protection, leakage protection, flame retardant
protection, overcurrent protection, intelligent temperature control protection, relay adhesion protection, input shutdown protection, vehicle specification level protection vehicle and protective personnel |
|
|
Warranty
|
12 months
|
|
|
Cooling mode
|
Natural cooling
|
|
Environment
|
Installation
|
Wall-mount/Pole-mount
|
|
|
Working Temperature
|
-25℃~+50℃
|
|
|
Storage temperature
|
-40℃~+60℃
|
|
|
Operating humidity
|
5%~95% no moisture condensation or frost
|
|
|
Working Height
|
<2000M
|
