Quick Details
-
Brand Name:
-
Tomato fence
-
Model Number:
-
customized
-
Weave Technique:
-
Hinge Joint, Fixed Knot, S Knot
-
Wire Diameter:
-
1.8mm, 2.0mm, 2.5mm, 2.8mm, 3.0mm or Customized
-
Height:
-
0.8m, 0.9m, 1.0m, 1.1m, 1.2m, 1.5m, 1.8m, 2m, 2.4m
-
Roll Length:
-
20m, 30m, 50m, 100m, 200m or Cutomized
-
Zinc Coating:
-
15-30g/Sqm, 60-100g/Sqm, 230-240g/Sqm
-
Joint Type:
-
Hinge Joint, Tight Lock Fixed Knot, S Knot
-
Post:
-
T Post, Y Post
-
Horizontal Wires:
-
7 Wires, 8 Wires, 9 Wires, 10 Wires, 11 Wires
-
Material:
-
Material
Quick Details
-
Frame Material:
-
Metal
-
Feature:
-
Easily Assembled, Sustainable, ECO FRIENDLY, FSC, Pressure Treated Timbers, Renewable Sources, Rodent Proof, Rot Proof, Tempered Glass, TFT, Waterproof
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
Tomato fence
-
Model Number:
-
customized
-
Weave Technique:
-
Hinge Joint, Fixed Knot, S Knot
-
Wire Diameter:
-
1.8mm, 2.0mm, 2.5mm, 2.8mm, 3.0mm or Customized
-
Height:
-
0.8m, 0.9m, 1.0m, 1.1m, 1.2m, 1.5m, 1.8m, 2m, 2.4m
-
Roll Length:
-
20m, 30m, 50m, 100m, 200m or Cutomized
-
Zinc Coating:
-
15-30g/Sqm, 60-100g/Sqm, 230-240g/Sqm
-
Joint Type:
-
Hinge Joint, Tight Lock Fixed Knot, S Knot
-
Post:
-
T Post, Y Post
-
Horizontal Wires:
-
7 Wires, 8 Wires, 9 Wires, 10 Wires, 11 Wires
-
Material:
-
Material
Farm Fence / Grassland Fence / Cattle Fence / Deer Fence / Hog Wire / Horse Fence
7 Holes/ SIZE: 0.81m x 27m
8 Holes/ SIZE: 0.99m x 27m
9 Holes/ SIZE: 1.19m x 27m
10 Holes/ SIZE: 1.42m x 27m
Easily Assembled, Sustainable, ECO FRIENDLY, FSC, Renewable Sources, Rodent Proof, Rot Proof, Tempered Glass, Waterproof
fence supplied in rolls, which is widely used for Agriculture farming and Livestock Ranching.
Square Knot Horse Fence also called square deal knot or "S" knot , is designed to use a separated wire to fasten the filler and the vertical wire together. It can assure maximum strength and prevent the fence from buckling or sagging. This design forms a smooth surface to prevent fence from injuring horses.
Hinge joint knot fencing
, always called
farm fencing
, providing easy installation because the hinge "gives" while retaining full
height for continuing protection and good looks.
Fixed knot fence
provides excellent control while maintaining animal maintenance. The fixed-knot woven wire fence consists of
strands of high carbon content steel wires that are joined together in a unique knot design.
.
|
Specification for Field Fence
|
|
|
|
|
|
|||||
|
No.
|
Specifications and Hole Sizes
|
|
Gross Weight (kg)
|
Top and Bottom Wire Dia.(mm)
|
Inner Wire Dia.(mm)
|
|||||
|
|
Type
|
Specifications(the incremental vertical hole sizes)
|
|
|
|
|||||
|
1
|
7/150/813/50
|
102+114+127+140+152+178
|
19.3
|
2.5
|
2
|
|||||
|
2
|
8/150/813/50
|
89(75)+89+102+114+127+140+152
|
20.8
|
2.5
|
2
|
|||||
|
3
|
8/150/902/50
|
89+102+114+127+140+152+178
|
21.6
|
2.5
|
2
|
|||||
|
4
|
8/150/1016/50
|
102+114+127+140+152+178+203
|
22.6
|
2.5
|
2
|
|||||
|
5
|
8/150/1143/50
|
114+127+140+152+178+203+229
|
23.6
|
2.5
|
2
|
|||||
|
6
|
9/150/991/50
|
89(75)+89+102+114+127+140+152+178
|
23.9
|
2.5
|
2
|
|||||
|
7
|
9/150/1245/50
|
102+114+127+140+152+178+203+229
|
26
|
2.5
|
2
|
|||||
|
8
|
10/150/1194/50
|
89(75)+89+102+114+127+140+152+178+203
|
27.3
|
2.5
|
2
|
|||||
|
9
|
10/150/1334/50
|
89+102+114+127+140+152+178+203+229
|
28.4
|
2.5
|
2
|
|||||
|
10
|
11/150/1422/50
|
89(75)+89+102+114+127+140+152+178+203+229
|
30.8
|
2.5
|
2
|
|||||
Field fence
is a kind of mesh used in cattle, goat, deer, and pig. It is used for grassland, pastures,protection of ecological projects, protecting grassland, forestry, highway, etc.
1. Fence roll: each roll was wrapped by plastic film (in order to prevent the fence roll be damp), and then on wooden or metal
pallet or in bulk
2. T/Y-post: in bundle
3. Or on your request
pallet or in bulk
2. T/Y-post: in bundle
3. Or on your request
