Quick Details
-
Color:
-
Full Color
-
Panel Size:
-
500*125mm
-
Place of Origin:
-
Henan, China
-
Model Number:
-
TP 3.9-7.8
-
Brightness:
-
4500nits
-
pixel density:
-
128*16
-
Contrast Ratio:
-
1500:1
-
Color Depth:
-
3000~18000
-
Lifespan (hours):
-
≥100000hrs
-
IP Rating:
-
30
-
HS Code:
-
8531 200000
-
Resolution:
-
32768/㎡
-
View Angle（H/V）:
-
±140°
-
Product name:
-
Transparent led screen
-
Cabinet size:
-
1000*500mm/1000*1000mm
-
Cabinet material:
-
Die Casting Aluminum
-
Refresh rate:
-
1920HZ/3840HZ
-
Installation:
-
Fixed/Hanging/Stacking
-
Certificate:
-
CE/Rhos/PSE/CCC
-
Warranty:
-
1-3 Years
-
Input Voltage:
-
AC110-240V
-
After Sale Service:
-
7/24 Technical Guidance
Quick Details
-
Application:
-
Indoor
-
Type:
-
LED
-
Brand Name:
-
JianHe
-
Color:
-
Full Color
-
Panel Size:
-
500*125mm
-
Place of Origin:
-
Henan, China
-
Model Number:
-
TP 3.9-7.8
-
Brightness:
-
4500nits
-
pixel density:
-
128*16
-
Contrast Ratio:
-
1500:1
-
Color Depth:
-
3000~18000
-
Lifespan (hours):
-
≥100000hrs
-
IP Rating:
-
30
-
HS Code:
-
8531 200000
-
Resolution:
-
32768/㎡
-
View Angle（H/V）:
-
±140°
-
Product name:
-
Transparent led screen
-
Cabinet size:
-
1000*500mm/1000*1000mm
-
Cabinet material:
-
Die Casting Aluminum
-
Refresh rate:
-
1920HZ/3840HZ
-
Installation:
-
Fixed/Hanging/Stacking
-
Certificate:
-
CE/Rhos/PSE/CCC
-
Warranty:
-
1-3 Years
-
Input Voltage:
-
AC110-240V
-
After Sale Service:
-
7/24 Technical Guidance
TECHNICAL PARAMETER
LED Panel Parameter
|
Model
|
TP2.8
|
TP3.9
|
TP3.9
|
TP5.2
|
|||
|
Pixel Pitch(mm)
|
H2.8-V5.6
|
H3.9-V7.8
|
H3.9-V7.8
|
H5.2-V10.4
|
|||
|
Pixel Matrix Per Sq.m
|
61,952
|
32,768
|
32,768
|
18,432
|
|||
|
Pixel Configuration
|
SMD1921
|
SMD1921
|
SMD1921
|
SMD1921
|
|||
|
Brightness(nits)
|
5000
|
2500
|
4500
|
5500
|
|||
|
Scan
|
1/11
|
1/8
|
1/8
|
1/6
|
|||
|
Cabinet Resolution
|
352*88
|
256*64
|
256*64
|
192*48
|
|||
|
Transparency
|
50%
|
70%
|
70%
|
80%
|
|||
|
Power Con.(Max/avg)
|
800/360W/SQ.M
|
400/180W/SQ.M
|
800/360W/SQ.M
|
800/360W/SQ.M
|
|||
|
Module Dimension
|
500*125mm/1.64*0.41ft
|
|
|
|
|||
|
Cabinet Dimension
|
1000*500mm/3.28*1.64ft
|
|
|
|
|||
|
Cabinet Material
|
CNC Aluminum
|
|
|
|
|||
|
Cabinet Weight
|
5KG
|
|
|
|
|||
|
Service Access
|
Front&Back
|
|
|
|
|||
|
Refresh Rate(Hz）
|
1,920
|
|
|
|
|||
|
Viewing Angle(H/N)
|
160/160
|
|
|
|
|||
|
IP Rate
|
IP30
|
|
|
|
|||
|
Operation Temperature
|
-40℃~45℃
|
|
|
|
|||
|
Input Voltage(AC)
|
100V Or 240V
|
|
|
|
|||
|
Model
|
TP7.8
|
TP-7.8
|
TP10.4
|
TP10.4
|
|||
|
Pixel Pitch(mm)
|
H7.8-V7.8
|
H7.8-V7.8
|
H10.4-V10.4
|
H10.4-V10.4
|
|||
|
Pixel Matrix Per Sq.m
|
16,384
|
16,384
|
9,216
|
9,216
|
|||
|
Pixel Configuration
|
SMD1921
|
SMD1921
|
SMD1921
|
SMD1921
|
|||
|
Brightness(nits)
|
3500
|
5500
|
3500
|
5500
|
|||
|
Scan
|
1/4
|
1/4
|
1/3
|
1/3
|
|||
|
Cabinet Resolution
|
128*64
|
128*64
|
96*48
|
96*48
|
|||
|
Transparency
|
70%
|
70%
|
80%
|
80%
|
|||
|
Power Con.(Max/avg)
|
400/180W/SQ.M
|
800/360W/SQ.M
|
400/180W/SQ.M
|
800/360W/SQ.M
|
|||
|
Module Dimension
|
500*125mm/1.64*0.41ft
|
|
|
|
|||
|
Cabinet Dimension
|
1000*500mm/3.28*1.64ft
|
|
|
|
|||
|
Cabinet Material
|
CNC Aluminum
|
|
|
|
|||
|
Cabinet Weight
|
5KG
|
|
|
|
|||
|
Service Access
|
Front & Back
|
|
|
|
|||
|
Refresh Rate(Hz）
|
1,920
|
|
|
|
|||
|
Viewing Angle(H/V)
|
160/160
|
|
|
|
|||
|
IP Rate
|
IP30
|
|
|
|
|||
|
Operation Temperature
|
-40℃~45℃
|
|
|
|
|||
|
Input Voltage(AC)
|
100V or240V
|
|
|
|
|||
