Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Blue Carbon
-
Model Number:
-
XN3-5kW
-
Input Voltage:
-
230Vac
-
Output Voltage:
-
170-280Vac
-
Output Current:
-
18A
-
Output Frequency:
-
50/60Hz
-
Size:
-
400*300*115mm
-
Certificate:
-
CE
-
Warranty:
-
5 years, 5 years
-
Weight:
-
9kg
-
Product name:
-
Pure Sine Inverter
-
Surge Power:
-
6-10kVA
-
Efficiency:
-
93%-97% ( HIGH EFFICIENCY )
-
Transfer Time:
-
10ms
-
Wave form:
-
Pure Sine Wave Invertor
-
Battery Voltage:
-
24/48 VDC
-
Floating:
-
27/54Vdc
-
Overcharge Protection:
-
33/63Vdc
-
Protection Degree:
-
IP21
Quick Details
-
Output Type:
-
Single, DUAL, Triple, Multiple, Three Phase
-
Type:
-
DC/AC Inverters
-
Inverter Efficiency:
-
95%
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Blue Carbon
-
Model Number:
-
XN3-5kW
-
Input Voltage:
-
230Vac
-
Output Voltage:
-
170-280Vac
-
Output Current:
-
18A
-
Output Frequency:
-
50/60Hz
-
Size:
-
400*300*115mm
-
Certificate:
-
CE
-
Warranty:
-
5 years, 5 years
-
Weight:
-
9kg
-
Product name:
-
Pure Sine Inverter
-
Surge Power:
-
6-10kVA
-
Efficiency:
-
93%-97% ( HIGH EFFICIENCY )
-
Transfer Time:
-
10ms
-
Wave form:
-
Pure Sine Wave Invertor
-
Battery Voltage:
-
24/48 VDC
-
Floating:
-
27/54Vdc
-
Overcharge Protection:
-
33/63Vdc
-
Protection Degree:
-
IP21
WE HAVE POWERWALL BATTERY TYPE, STACKER TYPE, AND LITHIUM BATTERY PACK:
12V 80AH/12V 100AH/12V 150AH/12V 180AH/12V 200AH/12V 250AH/12V 300AH
24V 80AH/24V 100AH/24V 150AH/24V 180AH/24V 200AH/24V 250AH/24V 300AH
48V 80AH/48V 100AH/48V 150AH/48V 180AH/48V 200AH/48V 250AH/48V 300AH
Product Description
Specification
|
Inverter Output
|
|
|
||
|
Rated Battery Voltage
|
24/48VDC
|
|
||
|
Rated Output Power
|
3KVA/3KW，5KVA / 5KW
|
|
||
|
Output Voltage Regulation
|
230Vac±5%
|
|
||
|
Output Voltage Waveform
|
Pure Sine Wave
|
|
||
|
Output Frequency
|
50/60Hz
|
|
||
|
Peak Effiffifficiency
|
90-93%
|
|
||
|
MPP Range Operation Voltage
|
120-450VDC
|
|
||
|
Max PV Array Open Circuit Voltage
|
500VDC
|
|
||
|
Surge Power
|
6kVA/10kVA
|
|
||
|
Capacity to Load AC
|
1KVA/1KW, 1.7KVA/1.7KW
|
|
||
|
Transfer Time
|
10ms
|
|
||
|
Protect
|
|
|
||
|
Battery reverse polarity protection
|
Fuse
|
|
||
|
Floating
|
27Vdc/54Vdc
|
|
||
|
General Parameters
|
|
|
||
|
Size (W×H×T)
|
400×300×115mm
|
|
||
|
Cooling Method
|
Smart Cooling
|
|
||
|
Temperature
|
-15℃~+60℃
|
|
||
|
Humidity
|
5%~95%
|
|
||
|
Altitude
|
<2000m Derating
|
|
||
|
Protection Degree
|
IP21
|
|
||
