Quick Details
-
Weight:
-
<20 Ton
-
Size:
-
Diameter<3.5m
-
Power:
-
<15kW
-
Weight (KG):
-
500 kg
-
Treatment Capacity:
-
5-70.6 m3/h per Set
-
Filtration Speed:
-
8-10 m/h
-
Shell Material:
-
Q235B or SS304
-
Filtration Medium:
-
Quartz Sand
-
Anti-corrosion Treatment:
-
Epoxy / FRP / Rubber Lined
-
Main Application:
-
Suspended Solid Removal
-
Power Source:
-
AC, 3-phase
-
Product Name:
-
Pressure sand filter for water filtration
-
Certificate:
-
ISO9001, 14001, OHSAS18001
-
Who We Are:
-
Manufacturer Started in Year 2006
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
JinWanTong
-
Material:
-
Seaworthy Packing
-
Weight:
-
<20 Ton
-
Size:
-
Diameter<3.5m
-
Power:
-
<15kW
-
Weight (KG):
-
500 kg
-
Treatment Capacity:
-
5-70.6 m3/h per Set
-
Filtration Speed:
-
8-10 m/h
-
Shell Material:
-
Q235B or SS304
-
Filtration Medium:
-
Quartz Sand
-
Anti-corrosion Treatment:
-
Epoxy / FRP / Rubber Lined
-
Main Application:
-
Suspended Solid Removal
-
Power Source:
-
AC, 3-phase
-
Product Name:
-
Pressure sand filter for water filtration
-
Certificate:
-
ISO9001, 14001, OHSAS18001
-
Who We Are:
-
Manufacturer Started in Year 2006
Product Description
Industrial rapid pressure sand filter is an ideal water treatment filter which use sand as filtration medium to remove suspended
https://jwthb.en.alibaba.com/product/60674441599-800636855/water_filter_purifier_machinery_Purification_Active_Sand_System_Multimedia_Mbbr_Activated_Carbon_Filter.html
solids & undissolved impurities like dust particles & heavy metals from water to reduce turbidity and TSS.
Considering to ocean transportation, our standard rapid pressure sand filter is designed with diameter from φ800 to φ3000mm and
with height from 2860 to 4480mm, these pre-engineered and pre-assembled units minimize installation and start-up costs.
Larger size water treatment filter is available, customized service is acceptable.
We are in Qingdao, the max. size industrial water filter which can be shipped from Qingdao port is with diameter 3.5m, by using
flat rack container.
As an experienced ISO9001 manufacturer started in year 2006, we provide one-stop services from project design to manufacturing,
installation and final commissioning.
Working Principles
Raw water access into rapid sand filter by water feeding pump and is channeled to filter top, and then falls on a bed of sand.
Filtered water then exits through laterals at filter bottom and the trapped dirt on the sand bed is removed via periodic
backwashing and infrequent sand replacement.
Product Uses
JG series water treatment filter is typically used for:
Drinking Water Purification:
As pretreatment process before UF and reverse osmosis system to remove suspended solids & undissolved impurities:
* Ground water purification
* Surface water purification(river, lake, pond)
* Alga removal
* Grit removal
* Iron and Maganese removal
* .....
Industrial Wastewater Purification:
Industrial water filter is mostly used after biological treatment process to further remove the residual TSS to reach expected
water quality. Industrial sand filter suits for almost all kinds of wastewater purification.
Industrial rapid pressure sand filter is an ideal water treatment filter which use sand as filtration medium to remove suspended
https://jwthb.en.alibaba.com/product/60674441599-800636855/water_filter_purifier_machinery_Purification_Active_Sand_System_Multimedia_Mbbr_Activated_Carbon_Filter.html
solids & undissolved impurities like dust particles & heavy metals from water to reduce turbidity and TSS.
Considering to ocean transportation, our standard rapid pressure sand filter is designed with diameter from φ800 to φ3000mm and
with height from 2860 to 4480mm, these pre-engineered and pre-assembled units minimize installation and start-up costs.
Larger size water treatment filter is available, customized service is acceptable.
We are in Qingdao, the max. size industrial water filter which can be shipped from Qingdao port is with diameter 3.5m, by using
flat rack container.
As an experienced ISO9001 manufacturer started in year 2006, we provide one-stop services from project design to manufacturing,
installation and final commissioning.
Working Principles
Raw water access into rapid sand filter by water feeding pump and is channeled to filter top, and then falls on a bed of sand.
Filtered water then exits through laterals at filter bottom and the trapped dirt on the sand bed is removed via periodic
backwashing and infrequent sand replacement.
Product Uses
JG series water treatment filter is typically used for:
Drinking Water Purification:
As pretreatment process before UF and reverse osmosis system to remove suspended solids & undissolved impurities:
* Ground water purification
* Surface water purification(river, lake, pond)
* Alga removal
* Grit removal
* Iron and Maganese removal
* .....
Industrial Wastewater Purification:
Industrial water filter is mostly used after biological treatment process to further remove the residual TSS to reach expected
water quality. Industrial sand filter suits for almost all kinds of wastewater purification.
|
NO.
|
Type
|
Tank size（m）
|
Capacity （m³/h）
|
Joint size filter water
Backwash effluent |
|
|
|
Materail mm
|
|||
|
NO.
|
Type
|
Tank size(m)
|
|
filter water
Backwash effluent |
filter out water
backwash water |
exhaust vent
|
Sampling mouth
|
|
|||
|
1
|
JG-100
|
carbon steel Φ1×2.22
|
～8
|
DN65
|
DN65
|
DN20
|
DN20
|
6
|
|||
|
2
|
JG-100
|
Φ1×2.22
|
～8
|
DN65
|
DN65
|
DN20
|
DN20
|
8
|
|||
|
3
|
JG-160
|
Φ1.6×2.4
|
～30
|
DN125
|
DN125
|
DN32
|
DN32
|
6
|
|||
|
4
|
JG-160
|
Φ1.6×2.4
|
～30
|
DN125
|
DN125
|
DN32
|
DN32
|
8
|
|||
