servo motor dc 24 volt 400w 24v motor bldc worm gear motor with brake and right angle planetary gearbox for tracked robot KPJ

servo motor dc 24 volt 400w 24v motor bldc worm gear motor with brake and right angle planetary gearbox for tracked robot KPJ

FOB Reference Price: Get Latest Price

≥1 Pieces

US $510

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Place of Origin:: Shandong, China

Model:: KY80AS0204-15BPGRL60-7

Product Name:: BLDC servo motor

Motor Type:: Brushless dc motor

Keywords:: servo motor dc 24 volt

Color:: Black

Motor Diameter:: 80mm

Gearbox Diameter:: 60mm

Encoder:: YES

Weight:: 7kg

Application:: AGV,Tracked car,Electric wheelchair

Quick Details

Speed(RPM):: 214rpm

Continuous Current(A):: 22A

Efficiency:: Ie 3

Place of Origin:: Shandong, China

Model:: KY80AS0204-15BPGRL60-7

Product Name:: BLDC servo motor

Motor Type:: Brushless dc motor

Keywords:: servo motor dc 24 volt

Color:: Black

Motor Diameter:: 80mm

Gearbox Diameter:: 60mm

Encoder:: YES

Weight:: 7kg

Application:: AGV,Tracked car,Electric wheelchair

servo motor dc 24 volt 400w 24v motor bldc worm gear motor with brake and right angle planetary gearbox for tracked robot KPJ

Model: KY80AS0204-15BPGRL60-7

Product overview

1.Product Features:

1)Protection grade:IP65, insulation grade:F

2)Winding overhang structure optimization, to minimize the copper loss and iron loss minimization, small volume, light weight, low temperature rise, high efficiency

3)Super high coercivity, the maximum magnetic energy product NdFe35 permanent magnetic materials, strong resistance to demagnetization, motor performance is stable.

4)Low noise, low vibration, low moment of inertia.

5)High torque, fast dynamic response, wide speed range, strong overload capacity (four times)

6) High Torque to inertia ratio&up to 25000Nm/kgm²

7)Fast dynamic response *time constant <20ms

8)Wide speed adjusting&feedback up to 1000:1

9)Steady speed precision up to 0.5%

10)High overload,2Mn/30s,3.5N.m/10s

11)Small volume and light

12)Silent,the lowest noise is only 45dB(A)

13)Protected with IP65,Class F insulation

2.Industry class:

a.The altitude should be over 1000 meters above sea level

b.Environment temperature:+5℃~+40℃

c.The month average tallest relative humidity is 90%,at the same the month average lowest temperature is less than 25

3.Product Parameter:

Model	KY80AS0204-15BPGRL60-7	Volt	24v
Power	400w	Rated Torque	2.55Nm
Rated Speed	1500rpm	Rated Current	21.3A
Peak Torque	7.65Nm	Line Resistance	0.025Ω
Rotor Constant	0.066mH	Torque constant	0.119Nm/A
Back EMF Constant	10.9/kr/min	Rotor Inertia	250Kg.m ² ×10 ^-6
Mechanical Time Constant	0.63ms	Electrical Time Constant	0.5ms
Encoder	2500ppr Incremental photoelectric	Gearbox Diameter	60mm
Brake	24vdc electromagnetic braking	Gear Ratio	1:7
Output speed	214r/min	Output rated torque	16.9N.m
gearbox efficiency	95%	Weight	7kg

4.Related Products:

Model	Volt	Power	Rated speed	Rated Current	Rated Torque	Peak Torque
Unit	V	W	r/min	A	N.m	N.m
KY60AS0201-30B	24	100	3000	5.4	0.318	0.95
KY60AS0202-30B	24	200	3000	10.4	0.63	1.89
KY80AS0202-15B	24/48	200	1500	9.4/4.7	1.27	3.8
KY80AS0204-15B	24/48	400	1500	21.3/10.6	2.55	7.65
KY80AS0204-30B	24/48	400	3000	18.8/9.4	1.27	3.8
KY110AS0405-15B	24/48	500	1500	24/14	3.1	10.8
KY110AS0408-15B	24/48	800	1500	44/22	5	17.9
KY110AS0410-15B	24/48	1000	1500	52/28	6.3	22
KY110AS0415-15	48	1500	1500	37.5	9.5	28
KY110AS0420-25B	48	2000	2500	55	7.6	26
KY130AS0430-15B	48	3000	1500	73	19	57
KY130AS0410-15B	48	1000	1500	28	6.3	22
KY130AS0415-15B	48	1500	1500	37.5	9.5	28

5.Drawing:

Right angle planetary reducer PGRL60-7

6.Speed-torque Curves

7. Matched controller:
