Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Sunord
-
Model Number:
-
SM-600/700/800/900D-2T
-
Input Voltage:
-
22V-60V
-
Output Voltage:
-
110V/80V-160V | 220V/180V-280V
-
Output Current:
-
2.6A-5A, 2.6A-5A
-
Output Frequency:
-
50Hz/48Hz-51Hz
-
Size:
-
234mm*205mm*46mm
-
Certificate:
-
CE/FCC, CE&FCC
-
Warranty:
-
10 years
-
Weight:
-
3.9kg
-
Inverter type:
-
Micro Inverter
-
Application:
-
Solar Power System Home
-
Cooling:
-
Smart cooling
-
Operating Temperature Range (℃):
-
-45~60℃, >45℃ Derating
-
Protection Degree:
-
IP67
-
Keyword:
-
Micro inverter
-
Brand:
-
Sunord
Quick Details
-
Output Type:
-
Single
-
Type:
-
DC/AC Inverters
-
Inverter Efficiency:
-
99.5%
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Sunord
-
Model Number:
-
SM-600/700/800/900D-2T
-
Input Voltage:
-
22V-60V
-
Output Voltage:
-
110V/80V-160V | 220V/180V-280V
-
Output Current:
-
2.6A-5A, 2.6A-5A
-
Output Frequency:
-
50Hz/48Hz-51Hz
-
Size:
-
234mm*205mm*46mm
-
Certificate:
-
CE/FCC, CE&FCC
-
Warranty:
-
10 years
-
Weight:
-
3.9kg
-
Inverter type:
-
Micro Inverter
-
Application:
-
Solar Power System Home
-
Cooling:
-
Smart cooling
-
Operating Temperature Range (℃):
-
-45~60℃, >45℃ Derating
-
Protection Degree:
-
IP67
-
Keyword:
-
Micro inverter
-
Brand:
-
Sunord
|
Model
|
SM-600D-2T
|
SM-700D-2T
|
SM-800D-2T
|
|||
|
Input Data (DC)
|
|
|
|
|||
|
Commonly used module power (W)
|
240-405+
|
280-470+
|
320-540+
|
|||
|
Maximum input voltage (V)
|
60
|
|
|
|||
|
MPPT voltage range (V)
|
22-60
|
|
|
|||
|
Min./Max. start voltage (V)
|
22
|
|
|
|||
|
Maximum input current (A)
|
2x11.5
|
2x11.5
|
2x12.5
|
|||
|
Maximum input short circuit current (A)
|
2x15
|
|
|
|||
|
Number of MPPTs
|
1
|
|
|
|||
|
Number of inputs per MPPT
|
2
|
|
|
|||
|
Output Data (AC)
|
|
|
|
|||
|
Rated output power (VA)
|
600
|
700
|
800
|
|||
|
Rated output current 110V/220V(A)
|
5/2.6
|
6.36/3.18
|
7.27/3.63
|
|||
|
Nominal output voltage/range (V)
|
110/80-160 220/180-280
|
|
|
|||
|
Nominal frequency/range (Hz)
|
48-51Hz/58-61Hz
|
|
|
|||
|
Power factor
|
> 95%
|
|
|
|||
|
Total harmonic distortion
|
< 5%
|
|
|
|||
|
Efficiency
|
|
|
|
|||
|
CEC peak efficiency
|
94%
|
|
|
|||
|
Nominal MPPT efficiency
|
99.50%
|
|
|
|||
|
Night power consumption (mW)
|
< 0.5w
|
|
|
|||
|
Mechanical Data
|
|
|
|
|||
|
Ambient temperature range (℃)
|
-40~65
|
|
|
|||
|
Storage temperature range (℃)
|
-40~+85
|
|
|
|||
|
Dimensions (W × H × D mm)
|
234 × 205 × 46
|
|
|
|||
|
Weight (kg)
|
3.99
|
3.99
|
4.0
|
|||
|
Enclosure rating
|
Outdoor-IP67
|
|
|
|||
|
Cooling
|
Natural convection
|
|
|
|||
|
Features
|
|
|
|
|||
|
Communication
|
Built-in Wi-Fi
|
|
|
|||
|
Topology
|
Galvanically Isolated HF Transformer
|
|
|
|||
|
Monitoring
|
SUNORD IOT Monitoring Platform
|
|
|
|||
|
Compliance
|
NB/T 32004-2018
|
|
|
|||
